IFM Threaded Adapter for Pressure Sensors: Max 100 bar, 1 in NPT, M18x1.5 - Threaded Adapters for Pressure Sensors
IFMThreaded Adapters for Pressure Sensors

IFM Threaded Adapter for Pressure Sensors: Max 100 bar, 1 in NPT, M18x1.5

The IFM Threaded Adapter for Pressure Sensors (SKU 801TA4, MPN U40080) is a stainless steel fitting with a 1 in NPT process connection and an M18x1.5 sensor connection. It includes a nitrile O-ring and is rated for a…

SKU 3G-OTH-174776

Brand
IFM
Item
Threaded Adapter for Pressure Sensors: Max 100 bar, 1 in NPT, M18x1.5
Category
Threaded Adapters for Pressure Sensors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

IFM
Manufacturer Part Number
U40080
Type
M18x1.5, With Nitrile O-Ring
NPT
1 in
Adapter Features
With Nitrile O-Ring
Fitting Material
Stainless Steel
Sensor Connection
M18x1.5
Adapter Process Connection
1 in NPT
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

IFM Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The IFM Threaded Adapter for Pressure Sensors (SKU 801TA4, MPN U40080) is a stainless steel fitting with a 1 in NPT process connection and an M18x1.5 sensor connection. It includes a nitrile O-ring and is rated for a maximum pressure of 100 bar.

Frequently Asked Questions

What is the IFM threaded adapter for pressure sensors used for?

The IFM threaded adapter (MPN U40080) connects a pressure sensor with an M18x1.5 thread to a process line having a 1 in NPT port. It is used in industrial hydraulic and pneumatic systems where a stainless steel fitting with a nitrile O-ring seal is required for pressures up to 100 bar.

What are the specifications of the IFM U40080 threaded adapter?

The IFM U40080 is a stainless steel adapter with a 1 in NPT process connection and an M18x1.5 sensor connection. It includes a nitrile O-ring and is rated for a maximum pressure of 100 bar. The fitting material is stainless steel, and the adapter features an integrated nitrile O-ring for sealing.

Where to buy the IFM U40080 threaded adapter worldwide?

3G Electric supplies the IFM U40080 threaded adapter worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us to source this adapter for your pressure sensor installation needs.

How to install the IFM threaded adapter for pressure sensors?

To install the IFM U40080 adapter, first ensure the process port is clean and has a 1 in NPT thread. Apply thread sealant to the NPT end, then tighten the adapter into the port. Connect the pressure sensor with an M18x1.5 thread to the adapter, using the nitrile O-ring for sealing. Torque to manufacturer specifications.

Used in

Common applications for IFM
Automotive assembly — IFM inductive proximity sensors (e.g., IFS243) for detecting metal parts on conveyor lines
Packaging machinery — IFM photoelectric sensors (e.g., OGE282) for object presence detection in high-speed wrapping systems
Hydraulic systems — IFM pressure transmitters (e.g., PX3227) for monitoring fluid pressure in industrial presses
Material handling — IFM RFID tags (e.g., E80347) for tracking pallets and containers in warehouse logistics
Machine safety — IFM light curtains (e.g., OY009S) for finger protection on automated assembly stations
Field wiring — IFM M12 connectors (e.g., E18163) for quick sensor replacement in food processing equipment

IFM Products

3G Electric supplies IFM threaded adapters for pressure sensors. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
