INSIZE Horizontal Dial Test Indicator: 0 in to 0.03 in, Horizontal, Inch - Dial Test Indicators - Horizontal & Tilted-Face Styles
INSIZEDial Test Indicators - Horizontal & Tilted-Face Styles

INSIZE Horizontal Dial Test Indicator: 0 in to 0.03 in, Horizontal, Inch

The INSIZE Horizontal Dial Test Indicator (MPN 2381-35) is a dial test indicator with a horizontal and tilted-face style, offering a measurement range of 0 in to 0.03 in and an accuracy of +/- 0.0005 in. It includes…

SKU 3G-OTH-408749

Brand
INSIZE
Item
Horizontal Dial Test Indicator: 0 in to 0.03 in, Horizontal, Inch
Category
Dial Test Indicators - Horizontal & Tilted-Face Styles
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

INSIZE
Manufacturer Part Number
2381-35
Type
Horizontal, Inch, +/- 0.0005 in
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

INSIZE Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The INSIZE Horizontal Dial Test Indicator (MPN 2381-35) is a dial test indicator with a horizontal and tilted-face style, offering a measurement range of 0 in to 0.03 in and an accuracy of +/- 0.0005 in. It includes a 5/32 in clamp and comes with a Short Form Certificate of Inspection with NIST Traceability.

Frequently Asked Questions

What is the INSIZE Horizontal Dial Test Indicator used for?

The INSIZE Horizontal Dial Test Indicator (MPN 2381-35) is used for precision measurement of small displacements, runout, and alignment in machining, quality control, and inspection applications. Its horizontal and tilted-face design allows easy reading in tight spaces on machine tools and fixtures.

What are the specifications of the INSIZE 2381-35 dial test indicator?

The INSIZE 2381-35 has a measurement range of 0 in to 0.03 in, accuracy of +/- 0.0005 in, and a 5/32 in clamp. It includes a Short Form Certificate of Inspection with NIST Traceability. The dial is horizontal with a tilted-face style for improved readability.

Where to buy the INSIZE 2381-35 dial test indicator worldwide?

You can source the INSIZE 2381-35 dial test indicator through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time.

How to maintain the INSIZE Horizontal Dial Test Indicator?

Keep the indicator clean and dry after use. Store it in its case to prevent damage. Avoid dropping or applying excessive force to the contact point. Periodically check calibration against a known standard; INSIZE provides a NIST-traceable certificate with this model.

Used in

Common applications for INSIZE
Quality control inspection — INSIZE digital calipers (1118-150R) for dimensional checks on machined parts.
Machine tool setup — INSIZE dial test indicators (2380-301) for aligning workpieces and measuring runout.
Hardness testing verification — INSIZE hardness test blocks (HDT-B-HV30D) for calibrating Vickers testers.
Layout and marking — INSIZE precision steel squares (4745-1120) for checking 45° angles on fixtures.
Workpiece holding — INSIZE magnetic V-blocks (6889-2) for securing cylindrical parts during measurement.
Groove and recess measurement — INSIZE small point jaw calipers (1169-150) for measuring internal features.
