INSIZE Reverse-Reading Dial Indicator - Lug Back: 0 in to 1 in, Inch, Plunger
The INSIZE Reverse-Reading Dial Indicator (MPN 2307-1RF) is a Continuous Reading Flat Back Dial Indicator with a lug back, featuring a 0-100 dial and 0.001 in graduation. It has an AGD 2 size and includes a Short…
SKU 3G-OTH-251370
Need installation or engineering help?
Ask a question
Product Description
The INSIZE Reverse-Reading Dial Indicator (MPN 2307-1RF) is a Continuous Reading Flat Back Dial Indicator with a lug back, featuring a 0-100 dial and 0.001 in graduation. It has an AGD 2 size and includes a Short Form Certificate Traceable to NIST.
Frequently Asked Questions
What is the INSIZE Reverse-Reading Dial Indicator used for?
The INSIZE Reverse-Reading Dial Indicator (MPN 2307-1RF) is used for precision measurement of linear displacement in machining, quality control, and inspection applications. Its reverse-reading dial allows operators to measure runout or taper where the indicator needle moves opposite to standard direction, common in toolroom setups.
What are the specifications of the INSIZE 2307-1RF dial indicator?
The INSIZE 2307-1RF is a reverse-reading dial indicator with a 0 in to 1 in range, 0.001 in graduation, and 0.001 in accuracy. It has an AGD 2 lug-back design, a 0-100 dial, and includes a Short Form Certificate Traceable to NIST. The plunger-style contact provides continuous reading for precise measurements.
Where to buy the INSIZE 2307-1RF dial indicator worldwide?
3G Electric supplies the INSIZE 2307-1RF reverse-reading dial indicator worldwide. As a global industrial equipment distributor since 1990, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time; we source and deliver this precision instrument to any country.
How to install the INSIZE lug-back dial indicator?
To install the INSIZE 2307-1RF, mount the lug back into a compatible fixture or stand using the provided mounting holes. Ensure the plunger contacts the workpiece perpendicularly. Zero the dial by rotating the bezel. For best results, follow generic dial indicator installation practices and avoid over-tightening the clamp.
Used in
Common applications for INSIZEINSIZE Products
3G Electric supplies INSIZE continuous reading flat back dial indicators. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
