INSIZE Spring Anvil: Spring Anvil, 36 mm x 100 mm Anvil Size
The INSIZE Spring Anvil (MPN ISY-500-1) is a CMM fixturing component made of steel, with an anvil size of 36 mm x 100 mm. It is designed for use with the ISY-500 system.
SKU 3G-OTH-401382
Need installation or engineering help?
Ask a question
Product Description
The INSIZE Spring Anvil (MPN ISY-500-1) is a CMM fixturing component made of steel, with an anvil size of 36 mm x 100 mm. It is designed for use with the ISY-500 system.
Frequently Asked Questions
What is the INSIZE Spring Anvil used for?
The INSIZE Spring Anvil (ISY-500-1) is a CMM fixturing component used to securely hold or position parts during dimensional inspection. It is designed for use with the ISY-500 system and is commonly applied in quality control and metrology labs for repeatable measurement setups.
What are the specifications of the INSIZE Spring Anvil?
The INSIZE Spring Anvil (MPN ISY-500-1) is made of steel and has an anvil size of 36 mm x 100 mm. It is a spring-loaded component designed for the ISY-500 CMM fixturing system. The manufacturer part number is ISY-500-1.
Where to buy the INSIZE Spring Anvil worldwide?
You can source the INSIZE Spring Anvil (ISY-500-1) through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time.
How to install the INSIZE Spring Anvil?
To install the INSIZE Spring Anvil, align the anvil base with the mounting holes on your ISY-500 fixture plate and secure it using the appropriate fasteners. Ensure the spring mechanism moves freely before placing your workpiece. Follow standard CMM fixturing best practices for repeatable setups.
Used in
Common applications for INSIZEINSIZE Products
3G Electric supplies INSIZE cmm fixturing components & accessories. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
