INTERMATIC Electromechanical Timer: 7 day, SPDT, 120V AC, 48 On/Off Cycles - Max - DIN Rail-Mounted Electromechanical Timer Switches
INTERMATICDIN Rail-Mounted Electromechanical Timer Switches

INTERMATIC Electromechanical Timer: 7 day, SPDT, 120V AC, 48 On/Off Cycles - Max

The INTERMATIC Electromechanical Timer (MPN MIL72ASWUZH-120) is a DIN Rail-Mounted SPDT timer switch operating at 120V AC with up to 48 On/Off cycles per week. This 7-day mechanical timer provides reliable scheduling…

SKU 3G-OTH-133129

Brand
INTERMATIC
Item
Electromechanical Timer: 7 day, SPDT, 120V AC, 48 On/Off Cycles - Max
Category
DIN Rail-Mounted Electromechanical Timer Switches
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

INTERMATIC
Manufacturer Part Number
MIL72ASWUZH-120
Type
SPDT, 48 On/Off Cycles - Max, Mechanical
AC
120V
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

INTERMATIC Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The INTERMATIC Electromechanical Timer (MPN MIL72ASWUZH-120) is a DIN Rail-Mounted SPDT timer switch operating at 120V AC with up to 48 On/Off cycles per week. This 7-day mechanical timer provides reliable scheduling for industrial control applications.

Frequently Asked Questions

What is the INTERMATIC MIL72ASWUZH-120 electromechanical timer used for?

The INTERMATIC MIL72ASWUZH-120 is a 7-day DIN rail-mounted electromechanical timer used to control lighting, HVAC, and industrial equipment schedules. It supports up to 48 on/off cycles per week with SPDT switching at 120V AC, ideal for building automation and process control.

What are the specifications of the INTERMATIC MIL72ASWUZH-120?

This INTERMATIC timer operates on 120V AC with SPDT contacts and a mechanical 7-day dial. It provides up to 48 on/off cycles per week. The DIN rail-mount design suits industrial panels. Manufacturer part number is MIL72ASWUZH-120.

Where to buy the INTERMATIC MIL72ASWUZH-120 worldwide?

3G Electric supplies the INTERMATIC MIL72ASWUZH-120 worldwide. As a global industrial distributor since 1990, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time.

How to install the INTERMATIC MIL72ASWUZH-120 timer?

Install the INTERMATIC MIL72ASWUZH-120 on a DIN rail in a panel. Connect 120V AC power to the input terminals and load to the SPDT output. Set the mechanical dial for desired on/off times. Follow local electrical codes and ensure power is off before wiring.

Used in

Common applications for INTERMATIC
Outdoor lighting control — INTERMATIC ET2145CR digital timer for parking lot lighting schedules
HVAC scheduling — INTERMATIC T7801B electromechanical timer for 7-day ventilation system cycling
Dusk-to-dawn lighting — INTERMATIC K4141C photocontrol for automatic street or sign lighting
Short-cycle pump control — INTERMATIC FD5MW spring-wound timer for sump pump test cycles
Plug-in appliance timing — INTERMATIC DT200LT digital plug-in timer for outdoor holiday lighting
Indoor load shedding — INTERMATIC ET2805C astronomic timer for office lighting based on daylight
