JOHNSON CONTROLS Mechanical Lube Oil Pressure Control: 9 psi, 120 sec Delay - Mechanical Lube Oil Pressure Controls
JOHNSON CONTROLSMechanical Lube Oil Pressure Controls

JOHNSON CONTROLS Mechanical Lube Oil Pressure Control: 9 psi, 120 sec Delay

The JOHNSON CONTROLS Mechanical Lube Oil Pressure Control (MPN P45NAA-5C) is a 24V AC device designed for use with Copeland compressors and non-corrosive refrigerants. It features a 9 psi pressure setting, a…

SKU 3G-OTH-67186

Brand
JOHNSON CONTROLS
Item
Mechanical Lube Oil Pressure Control: 9 psi, 120 sec Delay
Category
Mechanical Lube Oil Pressure Controls
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

JOHNSON CONTROLS
Manufacturer Part Number
P45NAA-5C
Product Type
Mechanical Lube Oil Pressure Control
Input Voltage
24V AC
Refrigerant Type
Non-Corrosive
For Compressor Brand
Copeland
Alarm Circuit Included
No
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

JOHNSON CONTROLS Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The JOHNSON CONTROLS Mechanical Lube Oil Pressure Control (MPN P45NAA-5C) is a 24V AC device designed for use with Copeland compressors and non-corrosive refrigerants. It features a 9 psi pressure setting, a 120-second time delay, and a 36-inch capillary length. This control does not include an alarm circuit.

Frequently Asked Questions

What is the JOHNSON CONTROLS P45NAA-5C mechanical lube oil pressure control used for?

The JOHNSON CONTROLS P45NAA-5C is used to protect Copeland compressors by monitoring lube oil pressure. It shuts down the compressor if oil pressure drops below 9 psi for more than 120 seconds, preventing damage from oil loss. It works with non-corrosive refrigerants and operates on 24V AC.

What are the specifications of the JOHNSON CONTROLS P45NAA-5C?

The JOHNSON CONTROLS P45NAA-5C is a mechanical lube oil pressure control with a 9 psi pressure setting, 120-second time delay, and 36-inch capillary length. It operates on 24V AC, is designed for Copeland compressors, and uses non-corrosive refrigerants. It does not include an alarm circuit.

Where to buy the JOHNSON CONTROLS P45NAA-5C worldwide?

You can source the JOHNSON CONTROLS P45NAA-5C from 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time; we supply this part for Copeland compressor applications.

How to install the JOHNSON CONTROLS P45NAA-5C lube oil pressure control?

Install the JOHNSON CONTROLS P45NAA-5C by mounting it near the compressor oil pump. Connect the 36-inch capillary to the oil pressure port and wire the 24V AC input to the control circuit. Set the 9 psi cut-out and 120-second delay per compressor specs. Always follow OEM guidelines for safe operation.
