JOHNSON CONTROLS Line Volt Mechanical Tstat: 15° to 55°F, Steel, Manual Reset - Two-Circuit Indoor Single-Stage Controls
JOHNSON CONTROLSTwo-Circuit Indoor Single-Stage Controls

JOHNSON CONTROLS Line Volt Mechanical Tstat: 15° to 55°F, Steel, Manual Reset

The JOHNSON CONTROLS A70HA-1C is a two-circuit indoor single-stage control with a temperature control range of 15° to 55°F and a 5°F differential. It features a manual reset, SPST switch action (open/close on rise)…

SKU 3G-OTH-67737

Brand
JOHNSON CONTROLS
Item
Line Volt Mechanical Tstat: 15° to 55°F, Steel, Manual Reset
Category
Two-Circuit Indoor Single-Stage Controls
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

JOHNSON CONTROLS
Manufacturer Part Number
A70HA-1C
Type
Steel, Manual Reset, 5°F
Voltage
120 to 600V AC
Differential Type
Manual Reset
Enclosure Material
Steel
Switch Type/Action
SPST, Open/Close on Rise
Temperature Differential
5°F
Temperature Control Range
15° to 55°F
Capillary Length/Bulb Diameter
20 ft Capillary, 20 ft x 1/8 in Bulb
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

JOHNSON CONTROLS Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The JOHNSON CONTROLS A70HA-1C is a two-circuit indoor single-stage control with a temperature control range of 15° to 55°F and a 5°F differential. It features a manual reset, SPST switch action (open/close on rise), and operates on 120 to 600V AC. The unit includes a 20 ft capillary with a 20 ft x 1/8 in bulb and is housed in a steel enclosure.

Frequently Asked Questions

What is the JOHNSON CONTROLS A70HA-1C used for?

The JOHNSON CONTROLS A70HA-1C is a line-voltage mechanical thermostat used for temperature control in industrial refrigeration, HVAC, and process equipment. It opens or closes a single-pole single-throw (SPST) circuit on temperature rise, with a manual reset for safety lockout.

What are the specifications of the JOHNSON CONTROLS A70HA-1C?

The A70HA-1C has a temperature control range of 15° to 55°F, a 5°F differential, and operates on 120 to 600V AC. It features a SPST switch action (open/close on rise), a 20 ft capillary with a 20 ft x 1/8 in bulb, and a steel enclosure with manual reset.

Where to buy the JOHNSON CONTROLS A70HA-1C worldwide?

3G Electric supplies the JOHNSON CONTROLS A70HA-1C to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time on this mechanical thermostat.

How to install the JOHNSON CONTROLS A70HA-1C thermostat?

Mount the steel enclosure securely, route the 20 ft capillary without kinking, and connect the SPST switch per the wiring diagram for 120 to 600V AC. Set the temperature control range between 15° and 55°F. The manual reset must be pressed after a trip event.
