JOHNSON CONTROLS Single Pressure Control: Fan Cycling, Auto Reset, 300 psi to 400 psi, Open on Rise - Single-Pressure Encapsulated Control Switches
JOHNSON CONTROLSSingle-Pressure Encapsulated Control Switches

JOHNSON CONTROLS Single Pressure Control: Fan Cycling, Auto Reset, 300 psi to 400 psi, Open on Rise

The JOHNSON CONTROLS Single Pressure Control: Fan Cycling (SKU 40G320, MPN P100CA-1C) is a single-pressure encapsulated control switch with an SPST contact form, rated for 240V AC. It features an Open on Rise switch…

SKU 3G-OTH-68333

Brand
JOHNSON CONTROLS
Item
Single Pressure Control: Fan Cycling, Auto Reset, 300 psi to 400 psi, Open on Rise
Category
Single-Pressure Encapsulated Control Switches
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

JOHNSON CONTROLS
Manufacturer Part Number
P100CA-1C
Type
Auto Reset, 300 psi to 400 psi, Open on Rise, SPST
Contact Form
SPST
Rated Voltage
240V AC
Switch Action
Open on Rise
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

JOHNSON CONTROLS Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The JOHNSON CONTROLS Single Pressure Control: Fan Cycling (SKU 40G320, MPN P100CA-1C) is a single-pressure encapsulated control switch with an SPST contact form, rated for 240V AC. It features an Open on Rise switch action and auto reset, with a pressure range of 300 psi to 400 psi.

Frequently Asked Questions

What is the JOHNSON CONTROLS P100CA-1C single pressure control used for?

The JOHNSON CONTROLS P100CA-1C is a fan cycling control used in commercial refrigeration and HVAC systems. It opens the electrical circuit on rising pressure (300 psi to 400 psi) to cycle condenser fans, maintaining proper head pressure and system efficiency.

What are the specifications of the JOHNSON CONTROLS P100CA-1C?

The JOHNSON CONTROLS P100CA-1C is a single-pressure encapsulated control switch with SPST contact form, rated 240V AC. It features Open on Rise switch action and auto reset, with a pressure range of 300 psi to 400 psi. The manufacturer part number is P100CA-1C.

Where to buy the JOHNSON CONTROLS P100CA-1C worldwide?

3G Electric supplies the JOHNSON CONTROLS P100CA-1C worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time.

How to install the JOHNSON CONTROLS P100CA-1C fan cycling control?

Install the JOHNSON CONTROLS P100CA-1C by mounting it on the refrigeration line or a bracket, connecting the pressure port, and wiring the SPST contacts in series with the fan motor. Ensure the pressure range (300 psi to 400 psi) matches your system. Follow standard electrical safety practices.
