JOHNSON CONTROLS Armored Capillary Tubing: 0.06 in ID, 24 in Lg, 1/4 in Connection - Armored Refrigeration Capillary Tubing
JOHNSON CONTROLSArmored Refrigeration Capillary Tubing

JOHNSON CONTROLS Armored Capillary Tubing: 0.06 in ID, 24 in Lg, 1/4 in Connection

The JOHNSON CONTROLS Armored Capillary Tubing (SKU 40G426, MPN SEC99AB-24C) is a refrigeration capillary tube with a 0.06 in ID, 24 in length, and 1/4 in connection featuring a 90° elbow. Made of copper, it includes…

SKU 3G-OTH-72239

Brand
JOHNSON CONTROLS
Item
Armored Capillary Tubing: 0.06 in ID, 24 in Lg, 1/4 in Connection
Category
Armored Refrigeration Capillary Tubing
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

JOHNSON CONTROLS
Manufacturer Part Number
SEC99AB-24C
Lg
24 in
Elbow
90°
Connection
1/4 in
Tubing Material
Copper
Control Side Depressor
Yes
Equipment Side Depressor
Yes
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

JOHNSON CONTROLS Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The JOHNSON CONTROLS Armored Capillary Tubing (SKU 40G426, MPN SEC99AB-24C) is a refrigeration capillary tube with a 0.06 in ID, 24 in length, and 1/4 in connection featuring a 90° elbow. Made of copper, it includes both control side and equipment side depressors.

Frequently Asked Questions

What is JOHNSON CONTROLS Armored Capillary Tubing used for?

JOHNSON CONTROLS Armored Capillary Tubing is used in refrigeration and HVAC systems to connect pressure controls to the system. The 0.06 in ID copper tube with a 90° elbow and 1/4 in connection allows for precise routing in tight spaces, while the armor protects against damage.

What are the specifications of JOHNSON CONTROLS Armored Capillary Tubing SEC99AB-24C?

The JOHNSON CONTROLS Armored Capillary Tubing (MPN SEC99AB-24C) has a 0.06 in inner diameter, 24 in length, and a 1/4 in connection with a 90° elbow. It is made of copper and includes both control side and equipment side depressors for easy installation.

Where to buy JOHNSON CONTROLS Armored Capillary Tubing worldwide?

You can source JOHNSON CONTROLS Armored Capillary Tubing from 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide locations, ensuring your order arrives reliably. Contact us for availability and lead times.

How to install JOHNSON CONTROLS Armored Capillary Tubing?

To install JOHNSON CONTROLS Armored Capillary Tubing, connect the 1/4 in fitting to the pressure control and equipment ports, ensuring the depressors are engaged. Route the 24 in copper tube with the 90° elbow to avoid kinks. Use proper tools to tighten connections without over-torquing.

Used in

Common applications for JOHNSON CONTROLS
Industrial refrigeration — Johnson Controls P170SA-1C dual pressure control for compressor protection in ammonia or halocarbon systems
Chiller plant automation — Johnson Controls VA7810-HGA-2 electric globe valve actuator for modulating chilled water flow in VG7000 series valves
Pneumatic HVAC retrofit — Johnson Controls T-4002-302 conversion kit for upgrading existing Robertshaw thermostats in commercial buildings
Cooling tower water management — Johnson Controls V-4332-1007 pneumatically actuated diaphragm valve for 3-way diverting of water flow
Boiler fuel oil pressure monitoring — Johnson Controls P545NCB-25C electronic lube oil pressure control with alarm for burner management systems
Process pressure sensing — Johnson Controls P599AAPS105C pressure transmitter with IP67 rating for washdown zones in food and beverage plants
