JOHNSON CONTROLS Actuator: Dampers, On/Off, Spring Return, 70 in-lb, 120V AC, Hardwired
The JOHNSON CONTROLS M9208-BAA-3 is a fail-safe spring-return damper actuator with a 90° stroke and CW/CCW shaft rotation. It operates on 120V AC input voltage, features a self-centering clamping shaft, and is…
SKU 3G-OTH-68085
Also listed as: M9208BAA3 · M9208 BAA 3
Local availability & support — Singapore
- Local office
- 20 Woodlands Link #09-05, Singapore 738733
- Phone
- +65 8878 8355
- Delivery
- Same-day or next-business-day delivery within Singapore for in-stock items; 7–14 days for factory-order parts from Europe.
- Payment
- Invoicing in SGD. PayNow, bank transfer, and corporate PO accepted.
- Ships to
- Singapore
Need installation or engineering help?
Ask a question
Product Description
The JOHNSON CONTROLS M9208-BAA-3 is a fail-safe spring-return damper actuator with a 90° stroke and CW/CCW shaft rotation. It operates on 120V AC input voltage, features a self-centering clamping shaft, and is hardwired for electrical connection. This NEMA 2 / IP54 rated actuator is building automation system compatible and delivers 70 in-lb of torque.
Frequently Asked Questions
What is the JOHNSON CONTROLS M9208-BAA-3 actuator used for?
The JOHNSON CONTROLS M9208-BAA-3 is a fail-safe spring-return damper actuator used in HVAC building automation systems. It controls air dampers in commercial buildings, providing 70 in-lb of torque with a 90° stroke. Its spring-return function ensures dampers close or open on power loss, protecting equipment and maintaining system safety.
What are the specifications of the JOHNSON CONTROLS M9208-BAA-3?
The M9208-BAA-3 operates on 120V AC input voltage, delivers 70 in-lb torque, and has a 90° stroke with CW/CCW shaft rotation. It features a self-centering clamping shaft, hardwired electrical connection, and NEMA 2 / IP54 enclosure rating. It is building automation system compatible and does not include an auxiliary switch.
Where to buy the JOHNSON CONTROLS M9208-BAA-3 worldwide?
3G Electric supplies the JOHNSON CONTROLS M9208-BAA-3 damper actuator worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time; we source and deliver this actuator to any international destination.
How to install the JOHNSON CONTROLS M9208-BAA-3 actuator?
Mount the actuator directly onto the damper shaft using the self-centering clamping mechanism. Ensure the shaft rotates freely and the stroke is set to 90°. Connect 120V AC power via hardwired terminals per the wiring diagram. Test the spring-return function by removing power to verify fail-safe operation. Follow local electrical codes.
Used in
Common applications for JOHNSON CONTROLSJOHNSON CONTROLS Products
3G Electric supplies JOHNSON CONTROLS fail-safe actuators with spring return. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
