JONARD TOOLS Underground Wire Tracer: 80 to 1000V (Receiver)/8 to 480V (Transmitter)
The JONARD TOOLS WCT-700 is a circuit tracer kit designed for underground wire tracing. It features a receiver with a voltage range of 80 to 1000V and a transmitter with a range of 8 to 480V, operating at 50 to 60 Hz…
SKU 3G-OTH-171578
Need installation or engineering help?
Ask a question
Product Description
The JONARD TOOLS WCT-700 is a circuit tracer kit designed for underground wire tracing. It features a receiver with a voltage range of 80 to 1000V and a transmitter with a range of 8 to 480V, operating at 50 to 60 Hz with a 33kHz signal output current. This plug-in kit is rated CAT III 600V.
Frequently Asked Questions
What is the JONARD TOOLS WCT-700 used for?
The JONARD TOOLS WCT-700 circuit tracer kit is used to locate and trace underground wires and cables. It helps identify breaks, shorts, and paths in buried electrical lines, making it essential for utility, construction, and maintenance work.
What are the specifications of the JONARD TOOLS WCT-700?
The WCT-700 has a receiver voltage range of 80 to 1000V and a transmitter range of 8 to 480V. It operates at 50 to 60 Hz with a 33kHz signal output current, is CAT III 600V rated, and uses a plug-in circuit connection.
Where to buy the JONARD TOOLS WCT-700 worldwide?
3G Electric supplies the JONARD TOOLS WCT-700 circuit tracer kit to customers worldwide. We handle full logistics, customs clearance, and delivery, ensuring you receive the genuine product regardless of your location.
How to use the JONARD TOOLS WCT-700 for underground tracing?
Connect the transmitter to the circuit using the plug-in connection, then use the receiver to follow the 33kHz signal along the ground. For best results, ensure the circuit is de-energized and follow standard safety practices for CAT III 600V environments.
