JW WINCO Male-End Leveling Mount: Swiveling Stud, 1/2"-13 Thread Size - Non-Skid Male Leveling Mounts
JW WINCONon-Skid Male Leveling Mounts

JW WINCO Male-End Leveling Mount: Swiveling Stud, 1/2"-13 Thread Size

The JW WINCO Male-End Leveling Mount (SKU 805X59, MPN 43-60-1/2X13-75-D1-SK) is a non-skid male leveling mount with a swiveling stud, 1/2"-13 thread size, and 3,597 lbf load capacity. It features a plain finish…

SKU 3G-OTH-517833

Brand
JW WINCO
Item
Male-End Leveling Mount: Swiveling Stud, 1/2"-13 Thread Size
Category
Non-Skid Male Leveling Mounts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

JW WINCO
Manufacturer Part Number
43-60-1/2X13-75-D1-SK
Type
3,597 lbf Capacity
Finish
Plain
Hex Size
11/16 in
Includes
Rubber Pad
Base Shape
Teardrop
Thread Size
1/2"-13
Load Capacity
3,597 lbf
Mounting Holes
Mounting Holes Included
Thrust Pad Material
TPE
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

JW WINCO Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The JW WINCO Male-End Leveling Mount (SKU 805X59, MPN 43-60-1/2X13-75-D1-SK) is a non-skid male leveling mount with a swiveling stud, 1/2"-13 thread size, and 3,597 lbf load capacity. It features a plain finish, teardrop base shape, TPE thrust pad, includes a rubber pad, and has an 11/16 in hex size with mounting holes included.

Frequently Asked Questions

What is a JW WINCO Male-End Leveling Mount used for?

A JW WINCO Male-End Leveling Mount levels and stabilizes industrial machinery, conveyors, and workstations. Its swiveling stud and TPE thrust pad reduce vibration and prevent skidding, supporting loads up to 3,597 lbf. 3G Electric supplies this mount across 14 industrial departments, including material handling and machining.

What are the specifications of the JW WINCO 43-60-1/2X13-75-D1-SK leveling mount?

The JW WINCO 43-60-1/2X13-75-D1-SK has a 1/2"-13 thread size, 3,597 lbf load capacity, plain finish, teardrop base, TPE thrust pad, 11/16 in hex size, and includes a rubber pad with mounting holes. 3G Electric sources this genuine JW WINCO part for global delivery.

Where to buy JW WINCO leveling mounts worldwide?

3G Electric supplies JW WINCO leveling mounts worldwide, handling full logistics and customs clearance. As a global industrial solutions provider, we source genuine parts like the 43-60-1/2X13-75-D1-SK and deliver to any international destination. Contact us for availability and lead time.

How to install a JW WINCO swiveling stud leveling mount?

To install a JW WINCO swiveling stud leveling mount, thread the 1/2"-13 stud into a matching tapped hole on the equipment base. Tighten with an 11/16 in hex wrench until level. The included rubber pad and TPE thrust pad provide non-skid grip. 3G Electric can advise on selection for your load requirements.
