JW WINCO4-Arm Knobs with Threaded Hole

JW WINCO Hand Knobs with Increased Clamping Force: Plastic w/ Steel Thread, M10 Thread

SKU 3G-OTH-517982

Brand

JW WINCO

Item

Hand Knobs with Increased Clamping Force: Plastic w/ Steel Thread, M10 Thread

Technical Specifications

JW WINCO

Manufacturer Part Number

10NDC7

Type

M10 Thread

Dia

63 mm

View Full Spec Sheet

Technical Documents

No technical documents available for this product.

Request documentation →

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

JW WINCO Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

The JW WINCO Hand Knob with Increased Clamping Force is a 4-arm knob with a threaded hole, featuring a plastic body with steel thread. It has a 63 mm diameter and M10 thread (MPN 10NDC7). 3G Electric interprets your demand for this OEM part, sourcing it across 14 industrial departments with specialist depth in controls and fastening components.

Frequently Asked Questions

What is a JW WINCO hand knob with increased clamping force used for?

This 4-arm knob with threaded hole provides a secure, ergonomic grip for manual clamping and adjustment on machinery, jigs, and fixtures. The increased clamping force design ensures reliable tightening without tools, common in industrial assembly and positioning applications.

What are the specifications of the JW WINCO hand knob 10NDC7?

The JW WINCO hand knob has a 63 mm diameter with M10 thread, a plastic body and steel thread insert. It is a 4-arm knob with threaded hole, designed for increased clamping force. The manufacturer part number is 10NDC7.

Where to buy JW WINCO hand knobs worldwide?

3G Electric supplies JW WINCO hand knobs worldwide, handling full logistics and customs clearance. We interpret your demand and source this OEM part across 14 industrial departments, including specialist expertise in controls and fastening components.

How to install a JW WINCO 4-arm knob with threaded hole?

Simply thread the M10 steel insert into the mating threaded hole or stud. Tighten by hand until secure; the 4-arm design provides ample torque for clamping. Avoid over-tightening to prevent damage to the plastic body. No tools are required for installation.

Used in

Common applications for JW WINCO

Machinery assembly — JW WINCO self-locking bearing locknuts (e.g., 1804.1-M50X1.5) for securing bearings on shafts in gearboxes and conveyors.

Fixture building — JW WINCO horizontal U-latch toggle clamps (e.g., 851.3-700-T6) for quick clamping in welding jigs and assembly fixtures.

Material handling — JW WINCO quick-release hoist rings (e.g., 1135-M12-17-ST) for lifting heavy components in manufacturing cells.

Shaft positioning — JW WINCO one-piece shaft collars (e.g., 5WG46/A) for retaining bearings or acting as stops on linear motion systems.

Linkage systems — JW WINCO stainless steel clevis rod ends (e.g., 8NXBIS) for connecting pneumatic cylinders or actuators in automated equipment.

Clamping arm extension — JW WINCO rigid clamping arm extenders (e.g., 801.1-85-16-ST) for increasing reach on toggle clamps in custom fixtures.
