KIPP Rear-Mount Insert w/Flat Face: 10 mm Dia, M5, 10 mm Ht
SKU 3G-OTH-180108
Need installation or engineering help?
Ask a question
Frequently Asked Questions
What is a KIPP rear-mount insert with flat face used for?
A KIPP rear-mount insert with flat face is used in jigs, fixtures, and workholding systems to provide a hardened, threaded mounting point for locating pins or stops. It is commonly applied in automotive, aerospace, and general manufacturing for precise positioning and repeatable clamping.
What are the specifications of the KIPP K0385.10108 rear-mount insert?
The KIPP K0385.10108 rear-mount insert has a 10 mm diameter, M5 thread, and 10 mm height. It features a smooth flat face and is made of steel. This insert is designed for rear mounting in fixture plates or tooling to accept locating pins or bolts.
Where to buy KIPP rear-mount inserts worldwide?
You can source KIPP rear-mount inserts worldwide through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to your facility. Contact us for availability and lead time on the K0385.10108 model.
How to install a KIPP rear-mount insert with flat face?
To install a KIPP rear-mount insert, drill a clearance hole in the fixture plate, then press or thread the insert into place from the rear side. Ensure the flat face sits flush against the mounting surface. Use a thread locker if vibration is present. Always follow standard workholding best practices.
Used in
Common applications for KIPPKIPP Products
3G Electric supplies KIPP rear-mount steel inserts with flat face. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
