KIPP Rear-Mount Insert w/Diamond Face: 10 mm Dia, M5, 12 mm Ht, Abrasive Grit
The KIPP Rear-Mount Insert w/Diamond Face (10 mm Dia) is a rear-mount stainless steel insert with an abrasive diamond face, featuring M5 threading and a 12 mm height. It is supplied with an abrasive grit and diamond…
SKU 3G-OTH-180003
Need installation or engineering help?
Ask a question
Product Description
The KIPP Rear-Mount Insert w/Diamond Face (10 mm Dia) is a rear-mount stainless steel insert with an abrasive diamond face, featuring M5 threading and a 12 mm height. It is supplied with an abrasive grit and diamond grit surface, identified by MPN K0385.10125.
Frequently Asked Questions
What is a KIPP rear-mount insert with diamond face used for?
A KIPP rear-mount insert with diamond face is used in industrial workholding and positioning fixtures to provide a durable, abrasive gripping surface. The diamond grit face prevents workpiece slippage during machining, assembly, or inspection. It is commonly applied in jigs, fixtures, and clamping systems where secure, repeatable part location is required.
What are the specifications of the KIPP K0385.10125 rear-mount insert?
The KIPP K0385.10125 is a rear-mount stainless steel insert with an abrasive diamond face. It has a 10 mm diameter, M5 thread, and 12 mm height. The insert features diamond grit for high-friction gripping. The manufacturer part number is K0385.10125, and the brand is KIPP.
Where to buy KIPP rear-mount inserts with diamond face worldwide?
KIPP rear-mount inserts with diamond face are available to order through 3G Electric, a global industrial equipment distributor. 3G Electric handles full logistics, customs clearance, and delivery to worldwide destinations. Contact 3G Electric for pricing and lead time on this KIPP K0385.10125 insert.
How to install a KIPP rear-mount insert with diamond face?
To install a KIPP rear-mount insert, drill and tap a M5 threaded hole in the fixture plate. Insert the diamond-faced stud from the rear side and secure it with a lock nut or set screw. Ensure the diamond face is flush or slightly protruding for optimal grip. Use standard torque values for M5 stainless steel fasteners.
Used in
Common applications for KIPPKIPP Products
3G Electric supplies KIPP rear-mount stainless steel inserts with abrasive diamond face. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
