KYOCERA Diamond Turning Insert: CNMG432PH

The KYOCERA CNMG432PH (also CNMG120408PH) diamond indexable turning insert is used for precision turning, facing, and boring operations on non-ferrous materials, composites, and abrasive plastics. It is common in automotive, aerospace, and general machining applications where high surface finish and tool life are required.

The KYOCERA CNMG432PHCA315 insert is designated as CNMG432PH and CNMG120408PH. It is a diamond indexable turning insert with a 80° rhombic shape, 4.76 mm thickness, and 12.7 mm inscribed circle. The manufacturer part number is CNMG432PHCA315. These specs define its geometry for standard turning holders.

You can source KYOCERA CNMG432PH diamond turning inserts worldwide through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to your facility. Contact us for availability and lead time. We supply genuine KYOCERA inserts for international machining operations.

To select the correct KYOCERA diamond turning insert, match the insert shape (CNMG), size (432PH or 120408PH), and grade to your workpiece material and operation. For non-ferrous and abrasive materials, diamond inserts offer superior wear resistance. Ensure your tool holder accepts the insert's inscribed circle and thickness. Consult KYOCERA's application guide for feed and speed recommendations.
