LEGRIS Push-Fit Adapter Fitting: 10 mm OD x 1/4 in Pipe Size, Push-to-Connect x MBSPP - Nickel-Plated Brass Tube Fittings
LEGRISNickel-Plated Brass Tube Fittings

LEGRIS Push-Fit Adapter Fitting: 10 mm OD x 1/4 in Pipe Size, Push-to-Connect x MBSPP

The LEGRIS Push-Fit Adapter Fitting (MPN 3601 10 13) is a nickel-plated brass tube fitting with a Push-to-Connect x MBSPP connection type, designed for 10 mm OD tubing and 1/4 in pipe size. It is a silver, brass…

SKU 3G-OTH-483056

Brand
LEGRIS
Item
Push-Fit Adapter Fitting: 10 mm OD x 1/4 in Pipe Size, Push-to-Connect x MBSPP
Category
Nickel-Plated Brass Tube Fittings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

LEGRIS
Manufacturer Part Number
3601 10 13
Type
Push-to-Connect x MBSPP, Brass, Silver
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

LEGRIS Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The LEGRIS Push-Fit Adapter Fitting (MPN 3601 10 13) is a nickel-plated brass tube fitting with a Push-to-Connect x MBSPP connection type, designed for 10 mm OD tubing and 1/4 in pipe size. It is a silver, brass fitting that enables quick, tool-free connections in pneumatic or fluid systems.

Frequently Asked Questions

What is a LEGRIS Push-Fit Adapter Fitting used for?

The LEGRIS Push-Fit Adapter Fitting (MPN 3601 10 13) is used to connect 10 mm OD tubing to a 1/4 in male BSPP threaded port in pneumatic or fluid systems. Its push-to-connect design enables tool-free installation, making it ideal for industrial automation, packaging, and material handling applications.

What are the specifications of the LEGRIS 3601 10 13?

The LEGRIS 3601 10 13 is a nickel-plated brass push-fit adapter fitting with a Push-to-Connect x MBSPP connection. It accepts 10 mm OD tubing and has a 1/4 in pipe size. The fitting is silver in color and designed for reliable sealing in compressed air and low-pressure fluid systems.

Where to buy LEGRIS push-fit fittings worldwide?

3G Electric supplies LEGRIS push-fit fittings like the 3601 10 13 to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time on this nickel-plated brass adapter fitting.

How to install a LEGRIS push-to-connect fitting?

To install a LEGRIS push-fit adapter, cut the 10 mm OD tubing square and deburr the end. Push the tubing fully into the fitting until it stops; the collet grips automatically. For removal, press the collet evenly and pull the tubing out. Ensure the system is depressurized before installation.

Used in

Common applications for LEGRIS
Pneumatic actuator speed control — LEGRIS miniature flow control valve 7665 04 10 for meter-out regulation on 4 mm tubing
Compressed air isolation for maintenance — LEGRIS lockout valve 7886 11 11 for 1/8 in NPT systems
Fluid shutoff in water or oil lines — LEGRIS brass ball valve 0492 07 17 with 3/8 in FNPT connections
Push-to-connect air distribution — LEGRIS nylon ball valve 7915 56 11 for 1/4 in tubing with male NPT adapter
Safety lockout on BSPP pneumatic circuits — LEGRIS lockout valve 7880 10 17 for 3/8 in BSPP systems
Compact on/off control in tight spaces — LEGRIS nylon ball valve 7913 56 00 with push-to-connect ports for 1/4 in tubing
