LEGRIS Push-Fit Elbow Fitting: 8 mm OD x 1/4 in Pipe Size, Push-to-Connect x MBSPP - Nylon & Nickel-Plated Brass Tube Fittings
LEGRISNylon & Nickel-Plated Brass Tube Fittings

LEGRIS Push-Fit Elbow Fitting: 8 mm OD x 1/4 in Pipe Size, Push-to-Connect x MBSPP

The LEGRIS Push-Fit Elbow Fitting (MPN 3199 08 13) is a nylon and nickel-plated brass tube fitting in a push-to-connect x MBSPP configuration, designed for 8 mm OD tubing with a 1/4 in pipe size. This black fitting…

SKU 3G-OTH-492380

Brand
LEGRIS
Item
Push-Fit Elbow Fitting: 8 mm OD x 1/4 in Pipe Size, Push-to-Connect x MBSPP
Category
Nylon & Nickel-Plated Brass Tube Fittings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

LEGRIS
Manufacturer Part Number
3199 08 13
Type
Push-to-Connect x MBSPP, Black, 10 PK
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

LEGRIS Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The LEGRIS Push-Fit Elbow Fitting (MPN 3199 08 13) is a nylon and nickel-plated brass tube fitting in a push-to-connect x MBSPP configuration, designed for 8 mm OD tubing with a 1/4 in pipe size. This black fitting is supplied in a 10-pack, offering a straightforward push-to-connect installation for industrial pneumatic or fluid systems.

Frequently Asked Questions

What is a LEGRIS Push-Fit Elbow Fitting used for?

A LEGRIS Push-Fit Elbow Fitting connects 8 mm OD tubing to 1/4 in BSPP male threads in pneumatic or fluid systems. Its push-to-connect design enables tool-free installation, making it ideal for industrial automation, packaging, and material handling applications where reliable, leak-free connections are required.

What are the specifications of the LEGRIS 3199 08 13 fitting?

The LEGRIS 3199 08 13 is a push-to-connect x MBSPP elbow fitting made of nylon and nickel-plated brass. It accepts 8 mm OD tubing with a 1/4 in pipe size, comes in black, and is sold in a 10-pack. This configuration suits compressed air and low-pressure fluid systems in industrial environments.

Where to buy LEGRIS push-fit fittings worldwide?

3G Electric supplies LEGRIS push-fit fittings worldwide, handling full logistics and customs clearance for global delivery. As a sourcing partner across 14 industrial departments, we provide genuine LEGRIS components like the 3199 08 13 elbow fitting, ensuring you get the right part for your pneumatic system.

How to install a LEGRIS push-to-connect elbow fitting?

To install a LEGRIS push-to-connect elbow fitting, cut the 8 mm tubing square, push it fully into the fitting until it stops, and pull gently to confirm secure engagement. For the MBSPP end, apply thread sealant and tighten to the port. Ensure the system is depressurized before installation to avoid injury.

Used in

Common applications for LEGRIS
Pneumatic actuator speed control — LEGRIS miniature flow control valve 7665 04 10 for meter-out regulation on 4 mm tubing
Compressed air isolation for maintenance — LEGRIS lockout valve 7886 11 11 for 1/8 in NPT systems
Fluid shutoff in water or oil lines — LEGRIS brass ball valve 0492 07 17 with 3/8 in FNPT connections
Push-to-connect air distribution — LEGRIS nylon ball valve 7915 56 11 for 1/4 in tubing with male NPT adapter
Safety lockout on BSPP pneumatic circuits — LEGRIS lockout valve 7880 10 17 for 3/8 in BSPP systems
Compact on/off control in tight spaces — LEGRIS nylon ball valve 7913 56 00 with push-to-connect ports for 1/4 in tubing
