LEGRIS Push-Fit Elbow Fitting: 10 mm OD x 1/4 in Pipe Size, Push-to-Connect x MBSPT - Nickel-Plated Brass Tube Fittings
LEGRISNickel-Plated Brass Tube Fittings

LEGRIS Push-Fit Elbow Fitting: 10 mm OD x 1/4 in Pipe Size, Push-to-Connect x MBSPT

The LEGRIS Push-Fit Elbow Fitting (MPN 3609 10 13) is a nickel-plated brass tube fitting with a 10 mm OD tube connection and a 1/4" MBSPT thread. It features a push-to-connect design for quick, tool-free installation…

SKU 3G-OTH-482886

Brand
LEGRIS
Item
Push-Fit Elbow Fitting: 10 mm OD x 1/4 in Pipe Size, Push-to-Connect x MBSPT
Category
Nickel-Plated Brass Tube Fittings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

LEGRIS
Manufacturer Part Number
3609 10 13
Type
Push-to-Connect x MBSPT, Brass, Silver
Thread Size A
1/4"
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

LEGRIS Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The LEGRIS Push-Fit Elbow Fitting (MPN 3609 10 13) is a nickel-plated brass tube fitting with a 10 mm OD tube connection and a 1/4" MBSPT thread. It features a push-to-connect design for quick, tool-free installation in pneumatic or fluid systems.

Frequently Asked Questions

What is a LEGRIS Push-Fit Elbow Fitting used for?

The LEGRIS Push-Fit Elbow Fitting (MPN 3609 10 13) is used to connect 10 mm OD tubing to a 1/4" MBSPT threaded port in pneumatic or fluid systems. Its push-to-connect design enables tool-free installation, making it ideal for industrial automation, packaging, and material handling applications.

What are the specifications of the LEGRIS 3609 10 13 fitting?

The LEGRIS 3609 10 13 is a nickel-plated brass push-fit elbow fitting. It connects 10 mm OD tubing to a 1/4" MBSPT male thread. The push-to-connect x MBSPT configuration allows quick assembly without tools. It is suitable for compressed air and low-pressure fluid systems.

Where to buy LEGRIS push-fit fittings in worldwide?

3G Electric supplies LEGRIS push-fit fittings like the 3609 10 13 to customers worldwide. As a global industrial sourcing partner, we handle logistics, customs clearance, and delivery to your location. Contact us for pricing and lead time on this nickel-plated brass elbow fitting.

How to install a LEGRIS push-to-connect elbow fitting?

To install the LEGRIS push-fit elbow, ensure the tube end is cut square and free of burrs. Push the tube firmly into the fitting until it stops. To release, press the collet evenly and pull the tube out. Always verify the 1/4" MBSPT thread is properly sealed with thread sealant for leak-free operation.
