LEGRIS Push-Fit Tee Fitting: 5/32 in OD x 5/32 in OD x 1/4 in Pipe Size, Tube x Tube x MUNF - Nylon & Nickel-Plated Brass Tube Fittings
LEGRISNylon & Nickel-Plated Brass Tube Fittings

LEGRIS Push-Fit Tee Fitting: 5/32 in OD x 5/32 in OD x 1/4 in Pipe Size, Tube x Tube x MUNF

The LEGRIS Push-Fit Tee Fitting (MPN 3103 04 20) is a nylon and nickel-plated brass tube fitting configured as Tube x Tube x MUNF, supplied in a 10-pack. It accommodates 5/32 in OD x 5/32 in OD x 1/4 in Pipe Size…

SKU 3G-OTH-492366

Brand
LEGRIS
Item
Push-Fit Tee Fitting: 5/32 in OD x 5/32 in OD x 1/4 in Pipe Size, Tube x Tube x MUNF
Category
Nylon & Nickel-Plated Brass Tube Fittings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

LEGRIS
Manufacturer Part Number
3103 04 20
Type
Tube x Tube x MUNF, 10 PK
Thread Size A
#10-32
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

LEGRIS Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The LEGRIS Push-Fit Tee Fitting (MPN 3103 04 20) is a nylon and nickel-plated brass tube fitting configured as Tube x Tube x MUNF, supplied in a 10-pack. It accommodates 5/32 in OD x 5/32 in OD x 1/4 in Pipe Size connections with a #10-32 thread size. 3G Electric sources this genuine LEGRIS component across 14 industrial departments, with specialist expertise in combustion, pumps, and controls ensuring accurate sourcing and support.

Frequently Asked Questions

What is the LEGRIS Push-Fit Tee Fitting used for?

The LEGRIS Push-Fit Tee Fitting (MPN 3103 04 20) is used to branch pneumatic or fluid lines in industrial automation, packaging, and material handling systems. Its Tube x Tube x MUNF configuration connects 5/32 in OD tubing to a 1/4 in pipe port with a #10-32 thread, enabling reliable air or low-pressure fluid distribution.

What are the specifications of the LEGRIS 3103 04 20 fitting?

The LEGRIS 3103 04 20 is a nylon and nickel-plated brass push-fit tee fitting. It has a Tube x Tube x MUNF configuration, accommodates 5/32 in OD x 5/32 in OD x 1/4 in Pipe Size, and features a #10-32 thread size. It is supplied in a 10-pack for multi-point installations.

Where to buy LEGRIS push-fit fittings in worldwide?

3G Electric supplies genuine LEGRIS push-fit fittings worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us to source the LEGRIS 3103 04 20 or other pneumatic components across 14 industrial departments, including combustion, pumps, and controls.

How to install a LEGRIS push-fit tee fitting?

To install a LEGRIS push-fit tee fitting, cut tubing square, deburr, and push fully into the collet until it stops. For the MUNF port, apply thread sealant to the #10-32 male thread and tighten to recommended torque. Ensure tubing is fully seated before pressurizing. Always follow manufacturer guidelines for safe operation.

Used in

Common applications for LEGRIS
Pneumatic actuator speed control — LEGRIS miniature flow control valve 7665 04 10 for meter-out regulation on 4 mm tubing
Compressed air isolation for maintenance — LEGRIS lockout valve 7886 11 11 for 1/8 in NPT systems
Fluid shutoff in water or oil lines — LEGRIS brass ball valve 0492 07 17 with 3/8 in FNPT connections
Push-to-connect air distribution — LEGRIS nylon ball valve 7915 56 11 for 1/4 in tubing with male NPT adapter
Safety lockout on BSPP pneumatic circuits — LEGRIS lockout valve 7880 10 17 for 3/8 in BSPP systems
Compact on/off control in tight spaces — LEGRIS nylon ball valve 7913 56 00 with push-to-connect ports for 1/4 in tubing
