LEGRIS Metal Pipe Straight: 180° Return, 1/8 in x 1/8 in, Nickel-Plated Brass - Threaded Medium-Pressure Pipe Fittings
LEGRISThreaded Medium-Pressure Pipe Fittings

LEGRIS Metal Pipe Straight: 180° Return, 1/8 in x 1/8 in, Nickel-Plated Brass

The LEGRIS Metal Pipe Straight: 180° Return is a threaded medium-pressure pipe fitting in a 1/8 in x 1/8 in nickel-plated brass configuration, rated for a maximum operating pressure of 870 psi. This 180° return…

SKU 3G-OTH-464267

Brand
LEGRIS
Item
Metal Pipe Straight: 180° Return, 1/8 in x 1/8 in, Nickel-Plated Brass
Category
Threaded Medium-Pressure Pipe Fittings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

LEGRIS
Manufacturer Part Number
0902 00 10
Type
1/8 in x 1/8 in, Nickel-Plated Brass, 870 psi
Lg
37/64 in
Maximum Operating Pressure
870 psi
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

LEGRIS Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The LEGRIS Metal Pipe Straight: 180° Return is a threaded medium-pressure pipe fitting in a 1/8 in x 1/8 in nickel-plated brass configuration, rated for a maximum operating pressure of 870 psi. This 180° return fitting (MPN 0902 00 10) measures 37/64 in in length, providing a compact solution for directional changes in medium-pressure piping systems.

Frequently Asked Questions

What is the LEGRIS Metal Pipe Straight 180° Return used for?

The LEGRIS Metal Pipe Straight 180° Return is a threaded medium-pressure pipe fitting used to reverse flow direction in pneumatic or hydraulic systems. Its compact 37/64 in length and nickel-plated brass construction suit tight spaces in industrial machinery, instrumentation, and control panels.

What are the specifications of the LEGRIS 0902 00 10?

The LEGRIS 0902 00 10 is a 1/8 in x 1/8 in nickel-plated brass 180° return fitting rated for 870 psi maximum operating pressure. It measures 37/64 in in length and is designed for medium-pressure threaded pipe connections.

Where to buy LEGRIS pipe fittings worldwide?

3G Electric supplies LEGRIS pipe fittings worldwide, handling full logistics and customs clearance. As a global industrial solutions provider, we source and deliver genuine components like the 0902 00 10 to any location. Contact us for a quote and delivery timeline.

How to install a LEGRIS 180° return fitting?

Install the LEGRIS 180° return fitting by applying thread sealant to the male threads and hand-tightening, then using a wrench for final torque. Avoid over-tightening to prevent damage to the nickel-plated brass. Ensure the system is depressurized before installation.
