LEGRIS Metal Pipe Elbow: 90° Elbow, 1/8 in x 1/8 in - Threaded Medium-Pressure Pipe Fittings
LEGRISThreaded Medium-Pressure Pipe Fittings

LEGRIS Metal Pipe Elbow: 90° Elbow, 1/8 in x 1/8 in

The LEGRIS Metal Pipe Elbow is a 90° threaded medium-pressure pipe fitting with a 1/8 in x 1/8 in Female BSPP Threaded x Male BSPT Threaded configuration (MPN 0913 00 10). It has a maximum operating pressure of 870 psi.

SKU 3G-OTH-464238

Brand
LEGRIS
Item
Metal Pipe Elbow: 90° Elbow, 1/8 in x 1/8 in
Category
Threaded Medium-Pressure Pipe Fittings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

LEGRIS
Manufacturer Part Number
0913 00 10
Type
1/8 in x 1/8 in, Female BSPP Threaded x Male BSPT Threaded
Maximum Operating Pressure
870 psi
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

LEGRIS Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The LEGRIS Metal Pipe Elbow is a 90° threaded medium-pressure pipe fitting with a 1/8 in x 1/8 in Female BSPP Threaded x Male BSPT Threaded configuration (MPN 0913 00 10). It has a maximum operating pressure of 870 psi.

Frequently Asked Questions

What is the LEGRIS 0913 00 10 metal pipe elbow used for?

The LEGRIS 0913 00 10 is a 90° metal pipe elbow used to change direction in medium-pressure fluid or gas lines. It connects female BSPP threaded ports to male BSPT threaded fittings, common in pneumatic, hydraulic, and industrial process systems.

What are the specifications of the LEGRIS 1/8 in x 1/8 in pipe elbow?

This LEGRIS elbow has a 1/8 in x 1/8 in Female BSPP Threaded x Male BSPT Threaded configuration, part number 0913 00 10. It is rated for a maximum operating pressure of 870 psi, suitable for medium-pressure applications.

Where to buy LEGRIS pipe fittings in worldwide?

3G Electric supplies LEGRIS pipe fittings like the 0913 00 10 elbow to customers worldwide. We handle full logistics, customs clearance, and delivery, ensuring you receive genuine industrial components regardless of your location.

How to install a LEGRIS BSPP to BSPT threaded elbow?

Apply appropriate thread sealant to the male BSPT thread, then hand-tighten the elbow into the female BSPP port. Use a wrench on the hex flats for final tightening, avoiding over-torque. Always verify pressure rating and thread compatibility before installation.

Used in

Common applications for LEGRIS
Pneumatic actuator speed control — LEGRIS miniature flow control valve 7665 04 10 for meter-out regulation on 4 mm tubing
Compressed air isolation for maintenance — LEGRIS lockout valve 7886 11 11 for 1/8 in NPT systems
Fluid shutoff in water or oil lines — LEGRIS brass ball valve 0492 07 17 with 3/8 in FNPT connections
Push-to-connect air distribution — LEGRIS nylon ball valve 7915 56 11 for 1/4 in tubing with male NPT adapter
Safety lockout on BSPP pneumatic circuits — LEGRIS lockout valve 7880 10 17 for 3/8 in BSPP systems
Compact on/off control in tight spaces — LEGRIS nylon ball valve 7913 56 00 with push-to-connect ports for 1/4 in tubing
