MARATHON MOTORS Encoder Kit: 1024 nsec, 5 to 26V DC, 120 mA Max Current, IP65, Hollow
The MARATHON MOTORS Encoder Kit (SKU 5TJC1, MPN KIT HS35A/B1024-NV) is a vector motor encoder with a hollow mounting and a resolution of 1024 nsec. Designed for use with Black Max motors, it operates on an output…
SKU 3G-OTH-55014
Need installation or engineering help?
Ask a question
Product Description
The MARATHON MOTORS Encoder Kit (SKU 5TJC1, MPN KIT HS35A/B1024-NV) is a vector motor encoder with a hollow mounting and a resolution of 1024 nsec. Designed for use with Black Max motors, it operates on an output voltage of 5 to 26V DC, with a maximum current of 120 mA and an IP65 rating. The encoder measures 4 1/2 inches in diameter.
Frequently Asked Questions
What is the MARATHON MOTORS Encoder Kit used for?
The MARATHON MOTORS Encoder Kit is used to provide precise speed and position feedback for Black Max vector motors. It is commonly applied in industrial automation, conveyor systems, and motor control loops where accurate rotational data is required.
What are the specifications of the MARATHON MOTORS Encoder Kit?
The encoder kit has a resolution of 1024 nsec, operates on 5 to 26V DC, and draws a maximum current of 120 mA. It features a hollow mounting, an IP65 rating, and a diameter of 4 1/2 inches. It is designed for use with Black Max motors.
Where to buy the MARATHON MOTORS Encoder Kit worldwide?
You can source the MARATHON MOTORS Encoder Kit through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time.
How to install the MARATHON MOTORS Encoder Kit?
Installation involves mounting the encoder onto the motor shaft using the hollow bore, ensuring proper alignment to avoid mechanical stress. Secure the encoder with the provided hardware, connect the 5 to 26V DC power and signal wires per the wiring diagram, and verify the IP65 seal is intact.
