MAXIM Welded Hydraulic Cylinder: 3 in Bore Dia., 10 in Stroke Lg, 18 1/4 in Retracted Lg - Swivel-Ball Mount Welded Hydraulic Cylinders
MAXIMSwivel-Ball Mount Welded Hydraulic Cylinders

MAXIM Welded Hydraulic Cylinder: 3 in Bore Dia., 10 in Stroke Lg, 18 1/4 in Retracted Lg

The MAXIM Welded Hydraulic Cylinder (SKU 833CV8, MPN 400528) is a swivel-ball mount welded hydraulic cylinder with a 3-inch bore diameter, 10-inch stroke length, and 18 1/4-inch retracted length. It is a…

SKU 3G-OTH-170620

Brand
MAXIM
Item
Welded Hydraulic Cylinder: 3 in Bore Dia., 10 in Stroke Lg, 18 1/4 in Retracted Lg
Category
Swivel-Ball Mount Welded Hydraulic Cylinders
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

MAXIM
Type
21,200 lb
Stroke Lg
10 in
attr95618
Double Acting
attr98893
MAXIM
Retracted Lg
18 1/4 in
Manufacturer Part Number
400528
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

MAXIM Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The MAXIM Welded Hydraulic Cylinder (SKU 833CV8, MPN 400528) is a swivel-ball mount welded hydraulic cylinder with a 3-inch bore diameter, 10-inch stroke length, and 18 1/4-inch retracted length. It is a double-acting cylinder rated for 21,200 lb. This MAXIM-branded unit is designed for industrial hydraulic applications requiring a compact, welded construction.

Used in

Common applications for MAXIM
Material handling equipment — MAXIM welded hydraulic cylinders (e.g., cross-tube mount, 4 in bore) for lift and tilt functions.
Agricultural machinery — MAXIM clevis-mount welded cylinders (e.g., 2.5 in bore, 14 in stroke) for implement control.
Construction equipment — MAXIM tie-rod cylinders (e.g., 2.5 in bore, 6 in stroke) for small actuator applications.
Mobile hydraulic systems — MAXIM DC power units (1.3 gpm, 12V) for powering dump trailers or lift gates.
Industrial automation — MAXIM swivel-ball mount cylinders (e.g., 1.5 in bore, 14 in stroke) for compact linear motion.
Off-road vehicles — MAXIM cross-tube mount cylinders (e.g., 6 in bore, 30 in stroke) for steering or suspension systems.

MAXIM Products

3G Electric supplies MAXIM swivel-ball mount welded hydraulic cylinders. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.

You might also need

Burners & Combustion →Pumps & Compressors →Spare Parts →All Products →

Similar products

Matched by specification & description
MAXIM Welded Hydraulic Cylinder: 3 in Bore Dia., 8 in Stroke Lg, 16 1/4 in Retracted Lg, 21,200 lb (MPN 400527). Key specifications — attr95618: Double Acting; attr98893: MAXIM.
