MAXXIMA Clearance Marker Light: Clearance Light, LED, Round, Surface Mount, Red - Clearance Lights
MAXXIMAClearance Lights

MAXXIMA Clearance Marker Light: Clearance Light, LED, Round, Surface Mount, Red

The MAXXIMA Clearance Marker Light (MPN M09100RCL) is an LED, round, surface-mount clearance light with a red lens and grommet mount. It features a PL-2 connector, SAE Lens Code P2, and an IP67 rating.

SKU 3G-OTH-495574

Brand
MAXXIMA
Item
Clearance Marker Light: Clearance Light, LED, Round, Surface Mount, Red
Category
Clearance Lights
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

MAXXIMA
Manufacturer Part Number
M09100RCL
Type
LED, Round, Surface Mount, Red, Grommet, IP67
Lens Color
Red
Mount Type
Grommet
SAE Lens Code
P2
Lighting Technology
LED
Electrical Connection
PL-2 Connector
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

MAXXIMA Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The MAXXIMA Clearance Marker Light (MPN M09100RCL) is an LED, round, surface-mount clearance light with a red lens and grommet mount. It features a PL-2 connector, SAE Lens Code P2, and an IP67 rating.

Frequently Asked Questions

What is the MAXXIMA M09100RCL clearance marker light used for?

The MAXXIMA M09100RCL is an LED clearance marker light used on trucks, trailers, and heavy equipment to indicate vehicle width and height. Its red lens, IP67 rating, and grommet mount make it suitable for harsh outdoor environments requiring reliable side or rear visibility.

What are the specifications of the MAXXIMA M09100RCL clearance light?

The MAXXIMA M09100RCL is an LED, round, surface-mount clearance light with a red lens, grommet mount, and PL-2 connector. It carries SAE Lens Code P2 and an IP67 rating for dust and water ingress protection. The manufacturer part number is M09100RCL.

Where to buy the MAXXIMA M09100RCL clearance light worldwide?

3G Electric supplies the MAXXIMA M09100RCL clearance light to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your location. Contact us for pricing and lead time on this LED clearance marker light.

How to install the MAXXIMA M09100RCL grommet-mount clearance light?

To install the MAXXIMA M09100RCL, drill a hole to the grommet diameter, insert the light through the grommet from the outside, and connect the PL-2 connector to the vehicle wiring. Ensure the grommet seals tightly against the panel to maintain the IP67 rating. Follow SAE guidelines for proper placement.
