MCKINNEY Butt Hinge: Steel, Full Mortise
The MCKINNEY Butt Hinge is a full mortise-mount butt hinge with a 1 15/16 in leaf width, made of steel with oil-impregnated bearings (MPN 4-1/2X4-1/2 TA2714 26DQC8).
SKU 3G-OTH-507674
Need installation or engineering help?
Ask a question
Product Description
The MCKINNEY Butt Hinge is a full mortise-mount butt hinge with a 1 15/16 in leaf width, made of steel with oil-impregnated bearings (MPN 4-1/2X4-1/2 TA2714 26DQC8).
Frequently Asked Questions
What is the MCKINNEY Butt Hinge used for?
The MCKINNEY Butt Hinge is used for mounting heavy commercial or industrial doors where full mortise installation provides strength and alignment. Its steel construction and oil-impregnated bearings suit high-traffic applications in factories, warehouses, and institutional buildings.
What are the specifications of the MCKINNEY Butt Hinge?
This MCKINNEY Butt Hinge is a full mortise type with a 1 15/16 in leaf width, made of steel, and features oil-impregnated bearings. The manufacturer part number is 4-1/2X4-1/2 TA2714 26DQC8. It is designed for durable, low-maintenance door operation.
Where to buy the MCKINNEY Butt Hinge worldwide?
3G Electric supplies the MCKINNEY Butt Hinge worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us to order this hinge or any industrial equipment across 14 departments.
How to install a full mortise butt hinge like the MCKINNEY?
Install a full mortise butt hinge by routing a recess in the door edge and frame to match the leaf dimensions. Use the hinge as a template to mark screw holes, then secure with appropriate fasteners. Ensure the hinge pin is vertical for smooth operation.
