MEPCO Steam Trap: Cast Iron, 1 1/4 in FNPT, 3,000 lb/hr, 30 psi Max., 450°F Max.
The MEPCO Cast Iron H-Pattern Float & Thermostatic Steam Trap (MPN 44-530A) is a steam trap with a 1 1/4 in FNPT connection, rated for 3,000 lb/hr capacity, 30 psi maximum pressure, and 450°F maximum temperature. It…
SKU 3G-OTH-71176
Also listed as: 44530A · 44 530A
Local availability & support — Singapore
- Local office
- 20 Woodlands Link #09-05, Singapore 738733
- Phone
- +65 8878 8355
- Delivery
- Same-day or next-business-day delivery within Singapore for in-stock items; 7–14 days for factory-order parts from Europe.
- Payment
- Invoicing in SGD. PayNow, bank transfer, and corporate PO accepted.
- Ships to
- Singapore
Need installation or engineering help?
Ask a question
Product Description
The MEPCO Cast Iron H-Pattern Float & Thermostatic Steam Trap (MPN 44-530A) is a steam trap with a 1 1/4 in FNPT connection, rated for 3,000 lb/hr capacity, 30 psi maximum pressure, and 450°F maximum temperature. It features a stainless steel float and is designed for horizontal installation as part of the Manufacturer Series 44.
Frequently Asked Questions
What is the MEPCO 44-530A steam trap used for?
The MEPCO 44-530A cast iron H-pattern float & thermostatic steam trap is used to automatically drain condensate from steam lines while preventing steam loss. It is suitable for industrial steam systems requiring a 3,000 lb/hr capacity at up to 30 psi and 450°F, typically in heating or process applications.
What are the specifications of the MEPCO 44-530A steam trap?
The MEPCO 44-530A is a cast iron H-pattern float & thermostatic steam trap with a 1 1/4 in FNPT connection. It has a maximum capacity of 3,000 lb/hr, maximum pressure of 30 psi, and maximum temperature of 450°F. The float is stainless steel, and it is designed for horizontal installation as part of MEPCO Series 44.
Where to buy the MEPCO 44-530A steam trap worldwide?
You can source the MEPCO 44-530A steam trap worldwide through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time; we provide competitive sourcing for MEPCO steam traps.
How to install the MEPCO 44-530A steam trap?
Install the MEPCO 44-530A steam trap in a horizontal orientation with the inlet and outlet properly aligned. Ensure the piping is clean and supports the trap's weight. Follow standard steam trap installation practices: install isolation valves upstream and downstream, and provide a strainer before the trap to protect the stainless steel float.
Used in
Common applications for MEPCOMEPCO Products
3G Electric supplies MEPCO cast iron h-pattern float & thermostatic steam traps. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
