MERSEN Fuse: Class RK5, TR-R Series, Time-Delay, 30 A, 250 V AC, 160 V DC - Time-Delay Cylindrical Fuses
MERSENTime-Delay Cylindrical Fuses

MERSEN Fuse: Class RK5, TR-R Series, Time-Delay, 30 A, 250 V AC, 160 V DC

The MERSEN TR-R Series TR30R is a Class RK5, time-delay cylindrical fuse rated for 30 A at 250 V AC and 160 V DC. This non-indicating fuse is designed for overcurrent protection in industrial electrical systems.

SKU 3G-OTH-25027

Brand
MERSEN
Item
Fuse: Class RK5, TR-R Series, Time-Delay, 30 A, 250 V AC, 160 V DC
Category
Time-Delay Cylindrical Fuses
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

MERSEN
Manufacturer Part Number
TR30R
Series
TR-R
Type
TR-R Series, Time-Delay, 30 A, Non-Indicating
AC
250 V
DC
160 V
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

MERSEN Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The MERSEN TR-R Series TR30R is a Class RK5, time-delay cylindrical fuse rated for 30 A at 250 V AC and 160 V DC. This non-indicating fuse is designed for overcurrent protection in industrial electrical systems.

Frequently Asked Questions

What is the MERSEN TR30R fuse used for?

The MERSEN TR30R is a Class RK5 time-delay cylindrical fuse rated 30 A, 250 V AC / 160 V DC. It protects motor circuits, transformers, and lighting systems from overloads and short circuits in industrial and commercial power distribution.

What are the specifications of the MERSEN TR30R fuse?

The MERSEN TR30R is a TR-R Series, time-delay, non-indicating fuse. Its AC rating is 250 V, DC rating is 160 V, and current rating is 30 A. The manufacturer part number is TR30R, and it is a Class RK5 cylindrical fuse.

Where to buy MERSEN TR30R fuses worldwide?

You can source the MERSEN TR30R fuse through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide locations. Contact us for availability and lead time.

How to select the correct MERSEN TR30R fuse for an application?

Select the MERSEN TR30R based on your circuit's voltage (250 V AC or 160 V DC) and continuous current (30 A). Ensure the Class RK5 time-delay characteristic matches motor or transformer inrush. Always verify the fuse holder's ampacity and ambient temperature derating.
