MERSEN Fuse: ATQ Series, Midget, Time-Delay, 8 A, 500 V AC, 13/32 in x 1 1/2 in - Time-Delay Cylindrical Fuses
MERSENTime-Delay Cylindrical Fuses

MERSEN Fuse: ATQ Series, Midget, Time-Delay, 8 A, 500 V AC, 13/32 in x 1 1/2 in

The MERSEN ATQ Series is a time-delay cylindrical fuse, specifically a midget fuse rated at 8 A and 500 V AC. It features a 13/32 in x 1 1/2 in non-indicating design, identified by manufacturer part number ATQ8.

SKU 3G-OTH-25749

Brand
MERSEN
Item
Fuse: ATQ Series, Midget, Time-Delay, 8 A, 500 V AC, 13/32 in x 1 1/2 in
Category
Time-Delay Cylindrical Fuses
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

MERSEN
Manufacturer Part Number
ATQ8
Series
ATQ
Type
Midget, Time-Delay, 8 A, 13/32 in x 1 1/2 in, Non-Indicating
AC
500 V
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

MERSEN Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The MERSEN ATQ Series is a time-delay cylindrical fuse, specifically a midget fuse rated at 8 A and 500 V AC. It features a 13/32 in x 1 1/2 in non-indicating design, identified by manufacturer part number ATQ8.

Frequently Asked Questions

What is the MERSEN ATQ8 fuse used for?

The MERSEN ATQ8 is a time-delay midget fuse rated at 8 A and 500 V AC. It protects industrial control circuits, transformers, and motor starters from overloads and short circuits, allowing harmless temporary inrush currents without nuisance opening.

What are the specifications of the MERSEN ATQ8 fuse?

The MERSEN ATQ8 is a 8 A, 500 V AC time-delay midget fuse from the ATQ Series. It has a non-indicating design with dimensions of 13/32 in x 1 1/2 in. The manufacturer part number is ATQ8, and it is a cylindrical fuse suitable for branch circuit protection.

Where to buy MERSEN ATQ8 fuses worldwide?

3G Electric supplies the MERSEN ATQ8 fuse worldwide. As a global industrial distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time; we source and deliver this MERSEN fuse to any country.

How to select the correct MERSEN ATQ8 fuse for an application?

To select the MERSEN ATQ8, verify your circuit voltage does not exceed 500 V AC and the continuous load current is below 8 A. The time-delay feature handles motor start-ups. Ensure the fuse holder accepts 13/32 in x 1 1/2 in dimensions. Consult MERSEN's application guide for specific coordination requirements.
