MERSEN Forklift Limiter Fuse: CNL Series, Bolt-On, Gen Purpose, 200 A, 80 V DC - Time-Delay Bolt-On Fuses
MERSENTime-Delay Bolt-On Fuses

MERSEN Forklift Limiter Fuse: CNL Series, Bolt-On, Gen Purpose, 200 A, 80 V DC

The MERSEN CNL Series is a time-delay bolt-on fuse designed for forklift limiter applications. This 200 A, 80 V DC indicating fuse (MPN CNL200) is rated for AC/DC circuits and is equivalent to the ANL & CNL series.

SKU 3G-OTH-24574

Brand
MERSEN
Item
Forklift Limiter Fuse: CNL Series, Bolt-On, Gen Purpose, 200 A, 80 V DC
Category
Time-Delay Bolt-On Fuses
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

MERSEN
Manufacturer Part Number
CNL200
Series
CNL
Type
Bolt-On, Gen Purpose, 200 A, Indicating, AC/DC
DC
80 V
Equivalent Fuse Series
ANL & CNL
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

MERSEN Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The MERSEN CNL Series is a time-delay bolt-on fuse designed for forklift limiter applications. This 200 A, 80 V DC indicating fuse (MPN CNL200) is rated for AC/DC circuits and is equivalent to the ANL & CNL series.

Frequently Asked Questions

What is the MERSEN CNL200 forklift limiter fuse used for?

The MERSEN CNL200 is a 200 A, 80 V DC time-delay bolt-on fuse used to protect forklift power circuits from overcurrent. Its indicating feature allows quick visual identification of a blown fuse, reducing downtime in material handling and industrial vehicle applications.

What are the specifications of the MERSEN CNL200 fuse?

The MERSEN CNL200 is a 200 A, 80 V DC bolt-on fuse from the CNL series. It is rated for AC/DC circuits, features time-delay and indicating functionality, and is equivalent to the ANL and CNL series. The manufacturer part number is CNL200.

Where to buy the MERSEN CNL200 fuse worldwide?

3G Electric supplies the MERSEN CNL200 fuse to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your location. Contact us for pricing and lead time on this and other MERSEN fuse series.

How to select the correct MERSEN CNL series fuse for a forklift?

Select a MERSEN CNL series fuse based on the forklift's operating voltage (80 V DC max) and continuous current draw (200 A for the CNL200). Ensure the bolt-on mounting matches your fuse block. For other ratings, consult the ANL/CNL equivalence chart or contact 3G Electric for guidance.
