MILWAUKEE Upper and Lower Crimping Die: W Style Dies, For Use With 2678-20 - Milwaukee Replacement Crimping Dies
MILWAUKEEMilwaukee Replacement Crimping Dies

MILWAUKEE Upper and Lower Crimping Die: W Style Dies, For Use With 2678-20

The MILWAUKEE Upper and Lower Crimping Die is a W Style Die replacement part for the M18™ FORCE LOGIC™ 2678-20 crimping tool, designed for electrical wire and cable crimping. This set includes two sizes (MPN…

SKU 3G-OTH-400960

Brand
MILWAUKEE
Item
Upper and Lower Crimping Die: W Style Dies, For Use With 2678-20
Category
Milwaukee Replacement Crimping Dies
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

MILWAUKEE
Manufacturer Part Number
49-16-W166
Type
For Use With 2678-20
Sizes
2
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

MILWAUKEE Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The MILWAUKEE Upper and Lower Crimping Die is a W Style Die replacement part for the M18™ FORCE LOGIC™ 2678-20 crimping tool, designed for electrical wire and cable crimping. This set includes two sizes (MPN 49-16-W166) and is manufactured by MILWAUKEE.

Frequently Asked Questions

What is the MILWAUKEE 49-16-W166 crimping die used for?

The MILWAUKEE 49-16-W166 upper and lower crimping die is a W Style replacement part for the M18™ FORCE LOGIC™ 2678-20 tool. It is designed for electrical wire and cable crimping, providing precise, repeatable connections in industrial and commercial wiring applications.

What are the specifications of the MILWAUKEE 49-16-W166 die set?

This die set includes two W Style dies (upper and lower) for use with the MILWAUKEE 2678-20 crimping tool. It is part of the M18™ FORCE LOGIC™ system and is designed for electrical wire and cable crimping. The manufacturer part number is 49-16-W166.

Where to buy MILWAUKEE 49-16-W166 crimping dies worldwide?

3G Electric supplies the MILWAUKEE 49-16-W166 crimping die set worldwide. As a global industrial equipment distributor since 1990, we handle full logistics, customs clearance, and delivery to your location. Contact us to source this genuine MILWAUKEE replacement part for your 2678-20 tool.

How to install MILWAUKEE W Style dies on the 2678-20 tool?

To install the MILWAUKEE upper and lower W Style dies, ensure the 2678-20 tool is disconnected from power. Align the die pins with the tool's ram and holder, then press firmly until they snap into place. Always verify secure fitment before crimping. Refer to the MILWAUKEE manual for detailed safety instructions.
