MITUTOYO Calibrated Indicator: 0 in to 0.03 in, Inch, 0.0001 in - Dial Test Indicators - Horizontal & Tilted-Face Styles
MITUTOYODial Test Indicators - Horizontal & Tilted-Face Styles

MITUTOYO Calibrated Indicator: 0 in to 0.03 in, Inch, 0.0001 in

The MITUTOYO Calibrated Indicator (MPN 513-473-10ECAL) is a test indicator with a 0 in to 0.03 in range and 0.0001 in resolution, featuring a 0-4-0 dial reading. It includes a contact point, knurled clamp ring…

SKU 3G-OTH-408757

Brand
MITUTOYO
Item
Calibrated Indicator: 0 in to 0.03 in, Inch, 0.0001 in
Category
Dial Test Indicators - Horizontal & Tilted-Face Styles
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

MITUTOYO
Manufacturer Part Number
513-473-10ECAL
Type
Inch, 0.0001 in
Dial Reading
0-4-0
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

MITUTOYO Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The MITUTOYO Calibrated Indicator (MPN 513-473-10ECAL) is a test indicator with a 0 in to 0.03 in range and 0.0001 in resolution, featuring a 0-4-0 dial reading. It includes a contact point, knurled clamp ring, 0.157" stem, 3/8" stem, and a Certificate of Calibration.

Frequently Asked Questions

What is the MITUTOYO 513-473-10ECAL calibrated indicator used for?

The MITUTOYO 513-473-10ECAL is a test indicator used for precision dimensional measurement in machining, quality control, and inspection. It measures small displacements from 0 to 0.03 inches with 0.0001 inch resolution, making it ideal for checking runout, alignment, and surface variations on industrial parts.

What are the specifications of the MITUTOYO 513-473-10ECAL indicator?

This MITUTOYO test indicator has a 0 to 0.03 inch range, 0.0001 inch resolution, and a 0-4-0 dial reading. It includes a contact point, knurled clamp ring, 0.157 inch stem, 3/8 inch stem, and comes with a Certificate of Calibration. The manufacturer part number is 513-473-10ECAL.

Where to buy the MITUTOYO 513-473-10ECAL indicator worldwide?

3G Electric supplies the MITUTOYO 513-473-10ECAL calibrated indicator worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time; we source and deliver this precision instrument to any country.

How to select the correct MITUTOYO test indicator for your application?

Select a MITUTOYO test indicator based on required range, resolution, and mounting style. For the 513-473-10ECAL, the 0 to 0.03 inch range and 0.0001 inch resolution suit fine measurements. Ensure the stem diameter (0.157 inch or 3/8 inch) matches your holder. Always verify the dial reading pattern, here 0-4-0, for your measurement needs.

Used in

Common applications for MITUTOYO
Automotive quality control — MITUTOYO digital outside micrometers (293-676-22) for measuring shaft diameters with IP65 protection.
Aerospace inspection — MITUTOYO splash-resistant calipers (552-160-10) for measuring large components up to 18 in with IP66 rating.
Machine shop setup — MITUTOYO dial test indicators (513-473-10E) for aligning workpieces and checking runout with 0.0001 in resolution.
Medical device manufacturing — MITUTOYO U-Wave transmitters (264-621) for wireless SPC data collection from calipers in cleanroom environments.
Tool and die maintenance — MITUTOYO flexible rules (182-222) for measuring curved surfaces and inside dimensions with etched decimal scales.
Laboratory microscopy — MITUTOYO halogen bulbs (383038) as replacement lamps for TM-500 series microscopes.

MITUTOYO Products

3G Electric supplies MITUTOYO dial test indicators - horizontal & tilted-face styles. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
