MURRELEKTRONIK Motor Suppressor: RC 3 BU, Resistor-Capacitor, 4 kW Motor Rating - Box-Mount Resistor-Capacitor EMC Suppressors
MURRELEKTRONIKBox-Mount Resistor-Capacitor EMC Suppressors

MURRELEKTRONIK Motor Suppressor: RC 3 BU, Resistor-Capacitor, 4 kW Motor Rating

The MURRELEKTRONIK Motor Suppressor RC 3 BU is a box-mount resistor-capacitor EMC suppressor rated for 690 V AC and 50 to 60 Hz. It features a single-core connection with self-securing M4 cable forks and is designed…

SKU 3G-OTH-40974

Brand
MURRELEKTRONIK
Item
Motor Suppressor: RC 3 BU, Resistor-Capacitor, 4 kW Motor Rating
Category
Box-Mount Resistor-Capacitor EMC Suppressors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

MURRELEKTRONIK
Manufacturer Part Number
23056
Type
Resistor-Capacitor
AC
690 V
Voltage
690 V AC
Frequency
50 to 60 Hz
Motor Rating
4 kW
Connection Type
Single Core
Connection Features
With Self-Securing M4 Cable Forks
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

MURRELEKTRONIK Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The MURRELEKTRONIK Motor Suppressor RC 3 BU is a box-mount resistor-capacitor EMC suppressor rated for 690 V AC and 50 to 60 Hz. It features a single-core connection with self-securing M4 cable forks and is designed for 4 kW motor applications.

Frequently Asked Questions

What is the MURRELEKTRONIK Motor Suppressor RC 3 BU used for?

The MURRELEKTRONIK Motor Suppressor RC 3 BU is a resistor-capacitor EMC suppressor used to reduce electromagnetic interference in 4 kW motor applications. It is commonly installed in industrial motor drives, pumps, and conveyors operating at 690 V AC and 50 to 60 Hz to protect sensitive electronics.

What are the specifications of the MURRELEKTRONIK Motor Suppressor RC 3 BU?

The MURRELEKTRONIK Motor Suppressor RC 3 BU (MPN 23056) is rated for 690 V AC and 50 to 60 Hz. It has a 4 kW motor rating, a resistor-capacitor type, single-core connection, and self-securing M4 cable forks. It is a box-mount EMC suppressor designed for industrial motor protection.

Where to buy the MURRELEKTRONIK Motor Suppressor RC 3 BU worldwide?

You can source the MURRELEKTRONIK Motor Suppressor RC 3 BU worldwide through 3G Electric. As a global industrial equipment distributor since 1990, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time.

How to install the MURRELEKTRONIK Motor Suppressor RC 3 BU?

To install the MURRELEKTRONIK Motor Suppressor RC 3 BU, mount the box securely near the motor. Connect the single-core wires using the self-securing M4 cable forks to the motor terminals, ensuring the voltage rating of 690 V AC is not exceeded. Follow standard EMC installation practices for optimal suppression.
