NTN Pillow Block Bearing: 3/4 in Bore, Cast Iron, Set Screws, 1 19/64 in Shaft Ht - General Purpose Pillow Block Ball Bearings
NTNGeneral Purpose Pillow Block Ball Bearings

NTN Pillow Block Bearing: 3/4 in Bore, Cast Iron, Set Screws, 1 19/64 in Shaft Ht

The NTN Pillow Block Bearing is a general purpose pillow block ball bearing with a 3/4 in bore, featuring a cast iron housing and set screw locking. It has a maximum speed of 6,660 RPM, a mounting bolt size of M10, a…

SKU 3G-OTH-107104

Brand
NTN
Item
Pillow Block Bearing: 3/4 in Bore, Cast Iron, Set Screws, 1 19/64 in Shaft Ht
Category
General Purpose Pillow Block Ball Bearings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

NTN
Manufacturer Part Number
UCP-3/4MFG1
Type
Cast Iron, Set Screws
Overall Lg
5 in
Shaft Ht
1 19/64 in
Maximum Speed
6,660 RPM
Mounting Bolt Size
M10
System of Measurement
Inch
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

NTN Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The NTN Pillow Block Bearing is a general purpose pillow block ball bearing with a 3/4 in bore, featuring a cast iron housing and set screw locking. It has a maximum speed of 6,660 RPM, a mounting bolt size of M10, a shaft height of 1 19/64 in, and an overall length of 5 in. This inch-system bearing is identified by manufacturer part number UCP-3/4MFG1.

Frequently Asked Questions

What is the NTN pillow block bearing used for?

The NTN pillow block bearing supports rotating shafts in industrial machinery such as conveyors, fans, and pumps. Its cast iron housing and set screw locking provide reliable mounting and alignment in general purpose applications.

What are the specifications of the NTN pillow block bearing UCP-3/4MFG1?

This NTN bearing has a 3/4 in bore, cast iron housing, set screw locking, and a maximum speed of 6,660 RPM. It uses an M10 mounting bolt, has a shaft height of 1 19/32 in, and an overall length of 5 in. System of measurement is inch.

Where to buy the NTN pillow block bearing worldwide?

3G Electric supplies the NTN pillow block bearing UCP-3/4MFG1 worldwide. We handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time.

How to install the NTN pillow block bearing?

Align the bearing housing on a flat surface, tighten the M10 mounting bolts to the base, and secure the shaft using the set screws. Ensure the shaft is clean and lubricated. Follow NTN's generic installation guidelines for proper fit and alignment.

Used in

Common applications for NTN
Automotive driveline — NTN tapered roller bearing assemblies (e.g., 4T-30303) for differential and wheel hub applications
Conveyor systems — NTN 4-bolt flange bearings (e.g., UCF211-200D1) for idler rollers and take-up units
Machine tool spindles — NTN duplex angular contact bearings (e.g., ML7006CVDUJ74S) for high-speed precision rotation
Industrial fans — NTN high-temperature radial ball bearings (e.g., 6004FT150) for oven and dryer exhaust systems
Pump drives — NTN radial ball bearings (e.g., 6008LLBC3/L627) for electric motor and pump shaft support
Agricultural equipment — NTN tapered roller bearing cones (e.g., LM29748L) for gearbox and PTO shaft assemblies
