NTN Pillow Block Bearing: 3 in Bore, Cast Iron, Set Screws, 3 1/4 in Shaft Ht - General Purpose Pillow Block Ball Bearings
NTNGeneral Purpose Pillow Block Ball Bearings

NTN Pillow Block Bearing: 3 in Bore, Cast Iron, Set Screws, 3 1/4 in Shaft Ht

The NTN UCP-3M is a general purpose pillow block ball bearing with a 3 in bore, constructed from cast iron and featuring set screw locking. This inch-system unit has a maximum speed of 2,100 RPM, a shaft height of 3…

SKU 3G-OTH-115865

Brand
NTN
Item
Pillow Block Bearing: 3 in Bore, Cast Iron, Set Screws, 3 1/4 in Shaft Ht
Category
General Purpose Pillow Block Ball Bearings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

NTN
Manufacturer Part Number
UCP-3M
Type
Cast Iron, Set Screws
Overall Lg
10.811 in
Shaft Ht
3 1/4 in
Maximum Speed
2,100 RPM
Mounting Bolt Size
3/4 in
System of Measurement
Inch
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

NTN Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The NTN UCP-3M is a general purpose pillow block ball bearing with a 3 in bore, constructed from cast iron and featuring set screw locking. This inch-system unit has a maximum speed of 2,100 RPM, a shaft height of 3 1/4 in, an overall length of 10.811 in, and accepts a 3/4 in mounting bolt.

Frequently Asked Questions

What is the NTN UCP-3M pillow block bearing used for?

The NTN UCP-3M is a general purpose pillow block ball bearing used to support rotating shafts in industrial machinery such as conveyors, fans, and pumps. Its cast iron housing and set screw locking provide reliable shaft retention in moderate-load applications across manufacturing, material handling, and HVAC systems.

What are the specifications of the NTN UCP-3M pillow block bearing?

The NTN UCP-3M has a 3 in bore, cast iron housing with set screw locking, a shaft height of 3 1/4 in, overall length of 10.811 in, and a maximum speed of 2,100 RPM. It uses inch-system measurements and accepts a 3/4 in mounting bolt. The manufacturer part number is UCP-3M.

Where to buy the NTN UCP-3M pillow block bearing worldwide?

3G Electric supplies the NTN UCP-3M pillow block bearing to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your facility. Contact us for pricing and lead time on this inch-system, cast iron bearing with set screw locking.

How to install the NTN UCP-3M pillow block bearing?

To install the NTN UCP-3M, first ensure the shaft is clean and free of burrs. Align the bearing with the mounting holes and secure using 3/4 in bolts. Tighten the set screws evenly against the shaft to prevent slippage. Verify shaft alignment and rotation before full-load operation. Follow NTN's generic installation guidelines for best results.
