NTN Pillow Block Bearing: 1 3/16 in Bore, Cast Iron, Set Screws, 1 55/64 in Shaft Ht - Medium Duty Pillow Block Ball Bearings
NTNMedium Duty Pillow Block Ball Bearings

NTN Pillow Block Bearing: 1 3/16 in Bore, Cast Iron, Set Screws, 1 55/64 in Shaft Ht

The NTN UCPX06-103D1 is a medium duty pillow block ball bearing with a 1 3/16 in bore, constructed from cast iron and featuring set screw locking. This inch-system unit has a 1 55/64 in shaft height, a 1/2 in…

SKU 3G-OTH-103320

Brand
NTN
Item
Pillow Block Bearing: 1 3/16 in Bore, Cast Iron, Set Screws, 1 55/64 in Shaft Ht
Category
Medium Duty Pillow Block Ball Bearings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

NTN
Manufacturer Part Number
UCPX06-103D1
Type
Cast Iron, Set Screws
Max Temp
250°F
Shaft Ht
1 55/64 in
Mounting Bolt Size
1/2 in
System of Measurement
Inch
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

NTN Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The NTN UCPX06-103D1 is a medium duty pillow block ball bearing with a 1 3/16 in bore, constructed from cast iron and featuring set screw locking. This inch-system unit has a 1 55/64 in shaft height, a 1/2 in mounting bolt size, and a maximum operating temperature of 250°F.

Frequently Asked Questions

What is the NTN UCPX06-103D1 pillow block bearing used for?

The NTN UCPX06-103D1 is a medium duty pillow block ball bearing used in industrial conveyor systems, agricultural machinery, and material handling equipment. It supports rotating shafts with a 1 3/16 in bore, handling moderate radial and axial loads in applications up to 250°F.

What are the specifications of the NTN UCPX06-103D1?

The NTN UCPX06-103D1 has a 1 3/16 in bore, cast iron housing, set screw locking, 1 55/64 in shaft height, and 1/2 in mounting bolt size. It is an inch-system unit with a maximum operating temperature of 250°F. The manufacturer part number is UCPX06-103D1.

Where to buy the NTN UCPX06-103D1 worldwide?

You can source the NTN UCPX06-103D1 through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time on this medium duty pillow block bearing.

How to install the NTN UCPX06-103D1 pillow block bearing?

To install the NTN UCPX06-103D1, align the shaft with the 1 3/16 in bore, tighten the set screws to lock the bearing onto the shaft, and secure the cast iron housing using 1/2 in bolts. Ensure the mounting surface is flat and the unit is not overheated beyond 250°F during operation.
