NTN BST45X75-1BP4 Angular Contact Thrust Bearing for Ball Screws
The NTN Ball Screw Support Bearing: 45X75 is a single, metric angular contact thrust bearing for ball screws, featuring a 45 mm bore and a 60° contact angle. This open bearing is ABEC 7 precision-rated with a…
SKU 3G-OTH-97335
Also listed as: BST45X751BP4 · BST45X75 1BP4
Local availability & support — Singapore
- Local office
- 20 Woodlands Link #09-05, Singapore 738733
- Phone
- +65 8878 8355
- Payment
- Invoicing in SGD. PayNow, bank transfer, and corporate PO accepted.
Need installation or engineering help?
Ask a question
Product Description
The NTN Ball Screw Support Bearing: 45X75 is a single, metric angular contact thrust bearing for ball screws, featuring a 45 mm bore and a 60° contact angle. This open bearing is ABEC 7 precision-rated with a thermoplastic cage, and is supplied as a single bearing (not matched). The bearing industry number is 45X75, with manufacturer part number BST45X75-1BP4.
Frequently Asked Questions
What is the NTN Ball Screw Support Bearing 45X75 used for?
This NTN angular contact thrust bearing supports ball screws in precision positioning systems. It handles axial loads in CNC machines, robotics, and linear motion assemblies. The 60° contact angle and ABEC 7 precision suit high-speed, high-accuracy applications.
What are the specifications of the NTN BST45X75-1BP4 bearing?
The NTN BST45X75-1BP4 is a single, metric angular contact thrust bearing with a 45 mm bore, 75 mm outer diameter, 60° contact angle, open design, ABEC 7 precision, and a thermoplastic cage. It is not matched and has bearing industry number 45X75.
Where to buy NTN ball screw support bearings worldwide?
3G Electric supplies NTN ball screw support bearings like the BST45X75-1BP4 worldwide. We handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time. As a global distributor, we source and deliver this NTN bearing to any country.
How to select the correct NTN ball screw support bearing?
Select based on bore size, contact angle, precision class, and cage material. For the BST45X75-1BP4, confirm a 45 mm shaft, 60° contact angle for axial loads, ABEC 7 for high precision, and thermoplastic cage for reduced noise. Ensure single bearing (not matched) suits your preload setup.
