NVENT CADDY Supporting Angle Brackets: Steel, 1 in Overall Lg - Beam, Wire Rod & Purlin Clamps
NVENT CADDYBeam, Wire Rod & Purlin Clamps

NVENT CADDY Supporting Angle Brackets: Steel, 1 in Overall Lg

The NVENT CADDY Supporting Angle Bracket (SKU 2KXL2, MPN AB) is a steel beam, wire rod, and purlin clamp with a galvanized finish and gray color. It has a 160 lb load capacity, overall dimensions of 1 in length, 3/4…

SKU 3G-OTH-04645

Brand
NVENT CADDY
Item
Supporting Angle Brackets: Steel, 1 in Overall Lg
Category
Beam, Wire Rod & Purlin Clamps
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

NVENT CADDY
Manufacturer Part Number
AB
Material
Steel
Color
Gray
Finish
Galvanized
UNSPSC
39121202
Standards
cULus
For Use With
Bolting Straps
Load Capacity
160 lb
Overall Width
3/4 in
Overall Height
1 in
Overall Length
1 in
Country of Origin
USA (subject to change)
Mounting Hole Diameter
0.25 in
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

NVENT CADDY Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The NVENT CADDY Supporting Angle Bracket (SKU 2KXL2, MPN AB) is a steel beam, wire rod, and purlin clamp with a galvanized finish and gray color. It has a 160 lb load capacity, overall dimensions of 1 in length, 3/4 in width, and 1 in height, and a 0.25 in mounting hole diameter. Designed for use with bolting straps, this cULus-listed bracket is made in the USA.

Frequently Asked Questions

What is the NVENT CADDY Supporting Angle Bracket used for?

The NVENT CADDY Supporting Angle Bracket is used to secure beam, wire rod, and purlin installations in industrial framing systems. It works with bolting straps to support loads up to 160 lb, making it suitable for electrical, mechanical, and HVAC support applications where a compact steel bracket is needed.

What are the specifications of the NVENT CADDY Supporting Angle Bracket?

The NVENT CADDY Supporting Angle Bracket (MPN AB) is made of galvanized steel with a gray finish. It has a 160 lb load capacity, overall dimensions of 1 in length, 3/4 in width, and 1 in height, and a 0.25 in mounting hole diameter. It is cULus listed and made in the USA.

Where to buy the NVENT CADDY Supporting Angle Bracket worldwide?

You can source the NVENT CADDY Supporting Angle Bracket through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time on this cULus-listed steel bracket.

How to install the NVENT CADDY Supporting Angle Bracket?

Install the NVENT CADDY Supporting Angle Bracket by securing it to the beam, wire rod, or purlin using compatible bolting straps through the 0.25 in mounting hole. Ensure the bracket is aligned to support the load within its 160 lb capacity. Follow standard industrial safety practices for overhead support installations.

Used in

Common applications for NVENT CADDY
Industrial manufacturing — NVENT CADDY K8 cable conduit clip hanger for securing 1/2 in conduit in control panels
Data center cabling — NVENT CADDY CAT1224SM J-hook clamp for managing cable bundles on overhead beams
Commercial electrical — NVENT CADDY MP2S communication mounting bracket for low-voltage device installation in walls
Utility infrastructure — NVENT CADDY 4BRT32WS bridle ring for supporting 2 in conduit on studs in substations
HVAC systems — NVENT CADDY 16M24SM beam clip with hanger for mounting pipe and conduit on steel beams
Telecommunications — NVENT CADDY MP1P ABS mounting bracket for single-gang low-voltage outlets in office spaces
