OMRON Enclosed Power Relay: Surface (Top Flange) Mounted, 25 A Current Rating
The OMRON G7L Series Enclosed Power Relay is a surface-mounted relay with a top flange mounting style and square base type. It features a DPST-NO contact configuration, screw terminal electrical connection, and an…
SKU 3G-OTH-36149
Need installation or engineering help?
Ask a question
Product Description
The OMRON G7L Series Enclosed Power Relay is a surface-mounted relay with a top flange mounting style and square base type. It features a DPST-NO contact configuration, screw terminal electrical connection, and an operating current of 25 A at 220V AC for both resistive and inductive loads. The relay operates on 12V DC and is identified by manufacturer part number G7L-2A-BUBJ-CB-DC12.
Frequently Asked Questions
What is the OMRON G7L-2A-BUBJ-CB-DC12 enclosed power relay used for?
The OMRON G7L-2A-BUBJ-CB-DC12 is a DPST-NO enclosed power relay rated for 25 A at 220V AC. It is used for switching resistive and inductive loads in industrial control panels, HVAC systems, and automation equipment where reliable high-current switching is required.
What are the specifications of the OMRON G7L-2A-BUBJ-CB-DC12 relay?
The OMRON G7L-2A-BUBJ-CB-DC12 is a surface-mounted relay with top flange mounting, square base, and screw terminals. It operates on 12V DC coil voltage, has a DPST-NO contact configuration, and carries a current rating of 25 A at 220V AC for both resistive and inductive loads.
Where to buy the OMRON G7L-2A-BUBJ-CB-DC12 relay worldwide?
3G Electric supplies the OMRON G7L-2A-BUBJ-CB-DC12 relay to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your location. Contact us for pricing and lead time on this OMRON relay.
How to install the OMRON G7L-2A-BUBJ-CB-DC12 relay?
Mount the OMRON G7L-2A-BUBJ-CB-DC12 relay using the top flange with screws on a flat surface. Connect the 12V DC coil voltage to the designated terminals and wire the DPST-NO contacts via the screw terminals. Ensure the load does not exceed 25 A at 220V AC. Follow standard electrical safety practices.
