OMRON Snap Action Switch: Roller Plunger Actuator, 1NO/1NC - Roller-Plunger Snap-Action Switches
OMRONRoller-Plunger Snap-Action Switches

OMRON Snap Action Switch: Roller Plunger Actuator, 1NO/1NC

The OMRON Z-15GQ22 is a roller-plunger snap-action switch from the Z Series, featuring a 1NO/1NC contact configuration with solder electrical connection. It is rated for 15 A at 250 V AC. This switch is designed for…

SKU 3G-OTH-39225

Brand
OMRON
Item
Snap Action Switch: Roller Plunger Actuator, 1NO/1NC
Category
Roller-Plunger Snap-Action Switches
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

OMRON
Manufacturer Part Number
Z-15GQ22
Series
Z
AC Contact Rating
15 A @ 250 V
Electrical Connection
Solder
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

OMRON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The OMRON Z-15GQ22 is a roller-plunger snap-action switch from the Z Series, featuring a 1NO/1NC contact configuration with solder electrical connection. It is rated for 15 A at 250 V AC. This switch is designed for industrial applications requiring precise actuation via a roller plunger mechanism.

Frequently Asked Questions

What is the OMRON Z-15GQ22 snap action switch used for?

The OMRON Z-15GQ22 is a roller-plunger snap-action switch used in industrial automation for precise position sensing, limit control, and interlock applications. Its roller plunger actuator provides reliable actuation in machinery, conveyors, and packaging equipment where a mechanical roller interface is required.

What are the specifications of the OMRON Z-15GQ22?

The OMRON Z-15GQ22 is a Z Series snap-action switch with a roller plunger actuator. It features a 1NO/1NC contact configuration, solder electrical connection, and an AC contact rating of 15 A at 250 V. The manufacturer part number is Z-15GQ22.

Where to buy the OMRON Z-15GQ22 worldwide?

You can source the OMRON Z-15GQ22 worldwide through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time; we provide competitive pricing and reliable supply for this OMRON switch.

How to install the OMRON Z-15GQ22 snap action switch?

To install the OMRON Z-15GQ22, mount the switch securely using the provided holes, ensuring the roller plunger aligns with the actuating cam or mechanism. Solder wires to the common, normally open, and normally closed terminals per your circuit. Verify the actuator travel and electrical rating (15 A at 250 V AC) before operation.
