OMRON Solid State Relay: Surface Mounted, 20 A Max Output Current, Phototriac - Surface-Mounted Relays
OMRONSurface-Mounted Relays

OMRON Solid State Relay: Surface Mounted, 20 A Max Output Current, Phototriac

The OMRON Solid State Relay: Surface Mounted (MPN G3NA-420B-UTU DC5-24) is a surface-mounted relay with a Form A switch configuration and AC output. It features a DC input current of 20 A, an output voltage range of…

SKU 3G-OTH-38481

Brand
OMRON
Item
Solid State Relay: Surface Mounted, 20 A Max Output Current, Phototriac
Category
Surface-Mounted Relays
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

OMRON
Manufacturer Part Number
G3NA-420B-UTU DC5-24
Type
Phototriac, AC Output
Finger Safe
Yes
Current Type
DC
Input Current
20 A
Mounting Style
Surface
Output Voltage
200 to 480V AC
Max Output Current
20 A
Switch Configuration
Form A
Voltage/Current Type
AC Output
Electrical Connection
Screw Clamp
Maximum Output Current without Heat Sink
20 A
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

OMRON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The OMRON Solid State Relay: Surface Mounted (MPN G3NA-420B-UTU DC5-24) is a surface-mounted relay with a Form A switch configuration and AC output. It features a DC input current of 20 A, an output voltage range of 200 to 480V AC, and a maximum output current without heat sink of 20 A. The relay is finger safe, uses a screw clamp electrical connection, and operates with a phototriac output.
