OMRON General Purpose Relay: Socket Mounted, 10 A Current Rating, 120V AC, DPDT
The OMRON LY Series General Purpose Relay is a socket-mounted, plug-in relay with a square base and flat pins. It features a DPDT contact configuration, an operating current of 5 A at 24V DC (Inductive Load), and a…
SKU 3G-OTH-39582
Need installation or engineering help?
Ask a question
Product Description
The OMRON LY Series General Purpose Relay is a socket-mounted, plug-in relay with a square base and flat pins. It features a DPDT contact configuration, an operating current of 5 A at 24V DC (Inductive Load), and a 10 A current rating at 120V AC. This relay is designed for plug-in electrical connection and is identified by manufacturer part number LY2N-AC110/120.
Frequently Asked Questions
What is the OMRON LY2N-AC110/120 relay used for?
The OMRON LY2N-AC110/120 is a general-purpose relay used for switching industrial loads in control panels, automation systems, and machinery. Its DPDT contacts and 10 A rating at 120V AC make it suitable for motor starters, conveyor controls, and HVAC equipment.
What are the specifications of the OMRON LY2N-AC110/120 relay?
The OMRON LY2N-AC110/120 is a socket-mounted, plug-in relay with a square base and flat pins. It has DPDT contacts, a 10 A current rating at 120V AC, and an operating current of 5 A at 24V DC (inductive load). It features 8 pins/terminals and is part of the LY Series.
Where to buy the OMRON LY2N-AC110/120 relay worldwide?
3G Electric supplies the OMRON LY2N-AC110/120 relay worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time.
How to install the OMRON LY2N-AC110/120 relay?
To install the OMRON LY2N-AC110/120, ensure the relay is plugged securely into a compatible square-base socket. Verify the coil voltage matches your 120V AC supply. Use proper wiring per the socket pinout and avoid exceeding the 10 A contact rating.
Used in
Common applications for OMRONOMRON Products
3G Electric supplies OMRON socket-mounted relays. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
