OMRON General Purpose Relays: Socket Mounted, 24V DC, 4PDT
The OMRON LY4-D DC24 is a socket-mounted general purpose relay from the LY Series, featuring a 24V DC coil, 4PDT contact configuration, and 14 pins/terminals. It has a square base type and plug-in mounting style with…
SKU 3G-OTH-39967
Need installation or engineering help?
Ask a question
Product Description
The OMRON LY4-D DC24 is a socket-mounted general purpose relay from the LY Series, featuring a 24V DC coil, 4PDT contact configuration, and 14 pins/terminals. It has a square base type and plug-in mounting style with a plug-in electrical connection.
Frequently Asked Questions
What is the OMRON LY4-D DC24 relay used for?
The OMRON LY4-D DC24 is a socket-mounted general purpose relay used for industrial control, automation, and switching applications. Its 4PDT contact configuration and 24V DC coil make it suitable for PLC output interfaces, motor controls, and signal switching in manufacturing and process industries.
What are the specifications of the OMRON LY4-D DC24?
The OMRON LY4-D DC24 is a socket-mounted relay from the LY Series with a 24V DC coil, 4PDT contact arrangement, and 14 pins/terminals. It features a square base type, plug-in mounting style, and plug-in electrical connection. The manufacturer part number is LY4-D DC24.
Where to buy the OMRON LY4-D DC24 relay worldwide?
3G Electric supplies the OMRON LY4-D DC24 relay worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time; we source and deliver this OMRON LY Series relay to any country.
How to install the OMRON LY4-D DC24 relay?
To install the OMRON LY4-D DC24, ensure the coil voltage matches your 24V DC supply. Plug the relay into a compatible square-base socket until it clicks. Verify the 4PDT contact wiring per your schematic. Use proper torque on terminal screws and avoid exceeding rated current to ensure reliable operation.
Used in
Common applications for OMRONOMRON Products
3G Electric supplies OMRON socket-mounted relays. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
