OMRON LY2-D-DC12 Socket-Mounted Relay, 12V DC, DPDT, 8 Pins, D Socket
The OMRON LY2-D-DC12 is a socket-mounted general-purpose relay from the LY series, featuring a DPDT contact configuration and 8 pins/terminals. It operates on 12V DC and uses a square base with plug-in mounting and…
SKU 3G-OTH-43213
Also listed as: LY2DDC12 · LY2 D DC12
Local availability & support — Singapore
- Local office
- 20 Woodlands Link #09-05, Singapore 738733
- Phone
- +65 8878 8355
- Delivery
- Same-day or next-business-day delivery within Singapore for in-stock items; 7–14 days for factory-order parts from Europe.
- Payment
- Invoicing in SGD. PayNow, bank transfer, and corporate PO accepted.
- Ships to
- Singapore
Need installation or engineering help?
Ask a question
Product Description
The OMRON LY2-D-DC12 is a socket-mounted general-purpose relay from the LY series, featuring a DPDT contact configuration and 8 pins/terminals. It operates on 12V DC and uses a square base with plug-in mounting and electrical connection. This relay is designed for industrial control applications requiring reliable switching.
Frequently Asked Questions
What is the OMRON LY2-D-DC12 relay used for?
The OMRON LY2-D-DC12 is a socket-mounted general-purpose relay used for reliable switching in industrial control panels, automation systems, and machinery. Its DPDT configuration and 12V DC coil make it suitable for signal routing, interlocking, and load control across manufacturing and process industries.
What are the specifications of the OMRON LY2-D-DC12?
The OMRON LY2-D-DC12 is a DPDT relay with 8 pins/terminals, a square base, and plug-in mounting. It operates on 12V DC and uses a D socket. The LY series design ensures consistent performance in industrial control applications requiring compact, socket-mounted switching.
Where to buy the OMRON LY2-D-DC12 relay worldwide?
3G Electric supplies the OMRON LY2-D-DC12 relay to customers worldwide. As a global industrial sourcing partner, we handle logistics, customs clearance, and delivery to your location. Contact us for a quote and lead time on this LY series DPDT relay.
How to install the OMRON LY2-D-DC12 relay?
To install the OMRON LY2-D-DC12, first ensure the coil voltage matches your 12V DC supply. Plug the relay into a compatible square-base D socket until fully seated. Verify wiring per the pin diagram, and secure the socket to a DIN rail or panel. Always de-energize circuits before handling.
Used in
Common applications for OMRONOMRON Products
3G Electric supplies OMRON socket-mounted relays. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
You might also need
Compatible alternatives & equivalents
- OMRON Plug-in relay from the LY Series with a square base and D socket. Features SPDT contact configuration and 8 pins/terminals for 24V DC operation. Used for general-purpose switching in industrial control and automation systems
- OMRON Plug-in relay from the LY Series with a square base and DPDT contact configuration. Operates on 110/120V AC and features 8 pins/terminals with PCB terminal connection. Suitable for general-purpose switching in control panels, automation systems, and industrial machinery
