PARKER Compression Fitting Elbow: 1/8 in OD x 1/8 in Pipe Fitting Size, Compression x MNPT - Standard Sleeve Brass Compression Fittings
PARKERStandard Sleeve Brass Compression Fittings

PARKER Compression Fitting Elbow: 1/8 in OD x 1/8 in Pipe Fitting Size, Compression x MNPT

The PARKER Compression Fitting Elbow (MPN 269C-2-2) is a standard sleeve brass compression fitting with a 1/8 in OD x 1/8 in Pipe Fitting Size, configured as Compression x MNPT, sold in a 10-pack. This product is a…

SKU 3G-OTH-482175

Brand
PARKER
Item
Compression Fitting Elbow: 1/8 in OD x 1/8 in Pipe Fitting Size, Compression x MNPT
Category
Standard Sleeve Brass Compression Fittings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

PARKER
Manufacturer Part Number
269C-2-2
Type
Compression x MNPT, 10 PK
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

PARKER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The PARKER Compression Fitting Elbow (MPN 269C-2-2) is a standard sleeve brass compression fitting with a 1/8 in OD x 1/8 in Pipe Fitting Size, configured as Compression x MNPT, sold in a 10-pack. This product is a genuine PARKER component, available through 3G Electric's sourcing and supply network.

Frequently Asked Questions

What is a PARKER compression fitting elbow used for?

A PARKER compression fitting elbow connects tubing to male threaded ports at a 90-degree angle. It is used in pneumatic, hydraulic, and instrumentation systems to route fluid or gas lines in tight spaces. The brass construction resists corrosion, making it suitable for industrial and commercial applications.

What are the specifications of the PARKER 269C-2-2 compression fitting?

The PARKER 269C-2-2 is a standard sleeve brass compression fitting elbow. It has a 1/8 in OD tube size and 1/8 in pipe fitting size, with Compression x MNPT connection. It is sold in a 10-pack. This genuine PARKER component is designed for reliable sealing in low- to medium-pressure systems.

Where to buy PARKER compression fittings in worldwide?

3G Electric supplies genuine PARKER compression fittings worldwide. We handle full logistics, customs clearance, and delivery to your facility. As a global industrial sourcing partner, we provide the right PARKER components for your application, including the 269C-2-2 elbow, with lead time on request.

How to install a PARKER compression fitting elbow?

To install a PARKER compression fitting elbow, slide the nut and sleeve onto the tubing, insert the tube fully into the fitting body, then tighten the nut by hand until snug. Use a wrench for an additional 1/4 to 1/2 turn. Do not overtighten. Always follow manufacturer guidelines for torque and tube support.

Used in

Common applications for PARKER
Injection molding machine proportional directional control — Parker solenoid coils and proportional valve cartridges for mold-closing and hydraulic actuation circuits
Construction equipment hydraulic steering and boom control — Parker directional control valves with solenoid actuation for excavator and loader hydraulic systems
Industrial press forming systems — Parker pressure-relief and proportional directional valves for tonnage control and cycle sequencing
Material-handling conveyor systems — Parker proportional control valves with solenoid pilot stages for smooth load acceleration and deceleration
Tire-building machinery — Parker solenoid-actuated directional cartridges for synchronized multi-axis hydraulic positioning
Forestry and mobile equipment — Parker valve spools and solenoid assemblies rated for harsh-environment hydraulic circuits and mobile-duty pressure cycling

PARKER Products

3G Electric supplies PARKER standard sleeve brass compression fittings. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
