PARKER Metal Pipe Elbow: 90° Elbow, Steel, 1/4 in x 1/8 in - Hydraulic Threaded Extreme-Pressure Pipe Fittings
PARKERHydraulic Threaded Extreme-Pressure Pipe Fittings

PARKER Metal Pipe Elbow: 90° Elbow, Steel, 1/4 in x 1/8 in

The PARKER Metal Pipe Elbow is a 90° hydraulic threaded extreme-pressure pipe fitting made of steel, with a 1/4 in x 1/8 in pipe size and Male NPT Threaded x Female NPT Threaded connections. It has a maximum…

SKU 3G-OTH-467644

Brand
PARKER
Item
Metal Pipe Elbow: 90° Elbow, Steel, 1/4 in x 1/8 in
Category
Hydraulic Threaded Extreme-Pressure Pipe Fittings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

PARKER
Manufacturer Part Number
1/4 X 1/8 CD-S
Type
Steel, 1/4 in x 1/8 in, Male NPT Threaded x Female NPT Threaded
Fitting Pipe Size
1/4 in x 1/8 in
Maximum Operating Pressure
5,000 psi
(DO NOT SEND) Manufacturer Location
Globally Sourced
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

PARKER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The PARKER Metal Pipe Elbow is a 90° hydraulic threaded extreme-pressure pipe fitting made of steel, with a 1/4 in x 1/8 in pipe size and Male NPT Threaded x Female NPT Threaded connections. It has a maximum operating pressure of 5,000 psi (MPN 1/4 X 1/8 CD-S).

Frequently Asked Questions

What is the PARKER 1/4 X 1/8 CD-S metal pipe elbow used for?

This PARKER 90° elbow is used in hydraulic systems to change flow direction under extreme pressure. It connects steel piping with 1/4 in male NPT and 1/8 in female NPT threads, rated for up to 5,000 psi in industrial fluid power applications.

What are the specifications of the PARKER 1/4 X 1/8 CD-S elbow?

The PARKER metal pipe elbow is a 90° steel fitting with a 1/4 in x 1/8 in pipe size. It has Male NPT Threaded x Female NPT Threaded connections and a maximum operating pressure of 5,000 psi. The part number is 1/4 X 1/8 CD-S.

Where to buy the PARKER 1/4 X 1/8 CD-S elbow worldwide?

3G Electric supplies the PARKER 1/4 X 1/8 CD-S elbow to customers worldwide. We handle full logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time on this hydraulic threaded extreme-pressure pipe fitting.

How to select the right PARKER hydraulic pipe elbow for my system?

Select a PARKER elbow by matching pipe size (1/4 in x 1/8 in), thread type (NPT), and pressure rating (5,000 psi). Ensure the 90° angle fits your layout. For extreme-pressure hydraulic lines, verify material compatibility with your fluid and temperature range.
