PARKER Metal Pipe Elbow: 90° Elbow, Steel, 1/8 in x 1/4 in - Hydraulic Threaded Extreme-Pressure Pipe Fittings
PARKERHydraulic Threaded Extreme-Pressure Pipe Fittings

PARKER Metal Pipe Elbow: 90° Elbow, Steel, 1/8 in x 1/4 in

The PARKER Metal Pipe Elbow is a 90° hydraulic threaded extreme-pressure pipe fitting, constructed of steel with a 1/8 in x 1/4 in size and Male NPT Threaded x Female NPT Threaded connections. It has a maximum…

SKU 3G-OTH-467238

Brand
PARKER
Item
Metal Pipe Elbow: 90° Elbow, Steel, 1/8 in x 1/4 in
Category
Hydraulic Threaded Extreme-Pressure Pipe Fittings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

PARKER
Manufacturer Part Number
1/8 X 1/4 CD-S
Type
Steel, 1/8 in x 1/4 in, Male NPT Threaded x Female NPT Threaded
Fitting Pipe Size
1/8 in x 1/4 in
Maximum Operating Pressure
5,000 psi
(DO NOT SEND) Manufacturer Location
Globally Sourced
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

PARKER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The PARKER Metal Pipe Elbow is a 90° hydraulic threaded extreme-pressure pipe fitting, constructed of steel with a 1/8 in x 1/4 in size and Male NPT Threaded x Female NPT Threaded connections. It has a maximum operating pressure of 5,000 psi (MPN 1/8 X 1/4 CD-S).

Frequently Asked Questions

What is the PARKER 1/8 X 1/4 CD-S metal pipe elbow used for?

This PARKER 90° elbow is used in hydraulic systems to change flow direction under extreme pressure. It connects male and female NPT threaded pipes of 1/8 in and 1/4 in sizes, suitable for high-pressure fluid power applications up to 5,000 psi.

What are the specifications of the PARKER 1/8 X 1/4 CD-S elbow?

The PARKER metal pipe elbow is a 90° steel fitting with a 1/8 in x 1/4 in size, male NPT threaded x female NPT threaded connections. It has a maximum operating pressure of 5,000 psi and is designed for hydraulic threaded extreme-pressure applications.

Where to buy PARKER 1/8 X 1/4 CD-S pipe fittings worldwide?

3G Electric supplies PARKER 1/8 X 1/4 CD-S elbows worldwide. We handle full logistics, customs clearance, and delivery to your site. As a global industrial solutions provider, we source and deliver genuine PARKER hydraulic fittings to meet your procurement needs.

How to install a PARKER 90° NPT threaded pipe elbow?

Apply thread sealant to the male NPT threads, then hand-tighten the PARKER elbow into the female port. Use a wrench to tighten an additional 1-2 turns, avoiding over-torquing. Ensure the 90° orientation aligns with your piping layout before final tightening.
