PARKER Metal Pipe Elbow: 3/4 in x 1 in, Male NPT Threaded x Female NPT Threaded - Threaded High-Pressure Pipe Fittings
PARKERThreaded High-Pressure Pipe Fittings

PARKER Metal Pipe Elbow: 3/4 in x 1 in, Male NPT Threaded x Female NPT Threaded

The PARKER Metal Pipe Elbow (MPN 3/4 X 1 CD-S) is a threaded high-pressure pipe fitting with a 3/4 in x 1 in size, featuring Male NPT Threaded x Female NPT Threaded connections in steel, rated for a maximum operating…

SKU 3G-OTH-466684

Brand
PARKER
Item
Metal Pipe Elbow: 3/4 in x 1 in, Male NPT Threaded x Female NPT Threaded
Category
Threaded High-Pressure Pipe Fittings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

PARKER
Manufacturer Part Number
3/4 X 1 CD-S
Type
Male NPT Threaded x Female NPT Threaded, 1,800 psi, Steel
Maximum Operating Pressure
1,800 psi
(DO NOT SEND) Manufacturer Location
Globally Sourced
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

PARKER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The PARKER Metal Pipe Elbow (MPN 3/4 X 1 CD-S) is a threaded high-pressure pipe fitting with a 3/4 in x 1 in size, featuring Male NPT Threaded x Female NPT Threaded connections in steel, rated for a maximum operating pressure of 1,800 psi.

Frequently Asked Questions

What is the PARKER 3/4 X 1 CD-S metal pipe elbow used for?

This PARKER threaded high-pressure pipe elbow connects steel piping in hydraulic or pneumatic systems where a 90-degree turn is needed. It handles up to 1,800 psi and is common in industrial fluid power, lubrication, and process lines requiring reliable, leak-resistant joints.

What are the specifications of the PARKER 3/4 X 1 CD-S elbow?

The PARKER metal pipe elbow (MPN 3/4 X 1 CD-S) has a 3/4 in x 1 in size with Male NPT Threaded x Female NPT Threaded connections. It is made of steel and rated for a maximum operating pressure of 1,800 psi. It is a threaded high-pressure pipe fitting.

Where to buy the PARKER 3/4 X 1 CD-S elbow worldwide?

3G Electric supplies the PARKER 3/4 X 1 CD-S metal pipe elbow to customers worldwide. We handle full logistics, customs clearance, and delivery to your site. Contact us for a quote and lead time on this threaded high-pressure fitting.

How to install a PARKER threaded high-pressure pipe elbow?

Apply a compatible thread sealant to the male NPT threads, then hand-tighten the PARKER elbow into the female port. Use a wrench to tighten an additional 1-2 turns—do not overtighten. Always verify the system is depressurized before installation and check for leaks at rated pressure.

Used in

Common applications for PARKER
Injection molding machine proportional directional control — Parker solenoid coils and proportional valve cartridges for mold-closing and hydraulic actuation circuits
Construction equipment hydraulic steering and boom control — Parker directional control valves with solenoid actuation for excavator and loader hydraulic systems
Industrial press forming systems — Parker pressure-relief and proportional directional valves for tonnage control and cycle sequencing
Material-handling conveyor systems — Parker proportional control valves with solenoid pilot stages for smooth load acceleration and deceleration
Tire-building machinery — Parker solenoid-actuated directional cartridges for synchronized multi-axis hydraulic positioning
Forestry and mobile equipment — Parker valve spools and solenoid assemblies rated for harsh-environment hydraulic circuits and mobile-duty pressure cycling
