PHOENIX Air Compressor Switch: Std, 35 psi – 150 psi, 1/4" FNPT - General Purpose Air Compressor Switches
PHOENIXGeneral Purpose Air Compressor Switches

PHOENIX Air Compressor Switch: Std, 35 psi – 150 psi, 1/4" FNPT

The PHOENIX Air Compressor Switch: Std (MPN 69MB7Y) is a general-purpose air compressor switch featuring a diaphragm actuation mechanism. It has a pressure range of 35 psi to 150 psi, with ON/OFF set points of 95 psi…

SKU 3G-OTH-169129

Brand
PHOENIX
Item
Air Compressor Switch: Std, 35 psi – 150 psi, 1/4" FNPT
Category
General Purpose Air Compressor Switches
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

PHOENIX
Manufacturer Part Number
69MB7Y
Type
35 psi – 150 psi
FNPT
1/4"
ON/OFF
95 psi / 125 psi
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

PHOENIX Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The PHOENIX Air Compressor Switch: Std (MPN 69MB7Y) is a general-purpose air compressor switch featuring a diaphragm actuation mechanism. It has a pressure range of 35 psi to 150 psi, with ON/OFF set points of 95 psi and 125 psi, and a 1/4" FNPT connection. This standard switch includes no additional options.

Frequently Asked Questions

What is the PHOENIX Air Compressor Switch used for?

The PHOENIX Air Compressor Switch (MPN 69MB7Y) is used to automatically control the start and stop of an electric-motor-driven air compressor based on tank pressure. It is suitable for general-purpose industrial and workshop compressors where reliable pressure regulation is required.

What are the specifications of the PHOENIX Air Compressor Switch?

The PHOENIX Air Compressor Switch has a pressure range of 35 psi to 150 psi, with ON/OFF set points of 95 psi and 125 psi. It features a diaphragm actuation mechanism and a 1/4" FNPT connection. This standard model includes no additional options.

Where to buy the PHOENIX Air Compressor Switch worldwide?

You can source the PHOENIX Air Compressor Switch (69MB7Y) through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time.

How to install the PHOENIX Air Compressor Switch?

Install the PHOENIX Air Compressor Switch by connecting the 1/4" FNPT port to the compressor tank or unloader line. Ensure the electrical contacts are wired according to the motor voltage and that the diaphragm is not damaged. Always depressurize the system before installation.
