Pratissoli PUMP SN7045 R

The Pratissoli PUMP SN7045 R is an industrial positive-displacement pump delivering 45 L/min at 210 bar, rated for 18.4 kW at 1450 rpm. This compact unit suits high-pressure hydraulic systems in manufacturing and…

SKU 3G-ITP-00786

Also listed as: SN7045000 · SN7045 000

Brand

Pratissoli

Item

PUMP SN7045 R

Local availability & support — Singapore

Local office: 20 Woodlands Link #09-05, Singapore 738733
Phone: +65 8878 8355
Delivery: Same-day or next-business-day delivery within Singapore for in-stock items; 7–14 days for factory-order parts from Europe.
Payment: Invoicing in SGD. PayNow, bank transfer, and corporate PO accepted.
Ships to: Singapore

Technical Specifications

Pratissoli

Flow Rate

45 L/min

Pressure

210 bar

Power

18.4 kW

Speed

1450 RPM

Weight

43 kg

Dimensions

387 mm

Power

25 HP

Flow (US)

11.9 GPM

Pressure

21 MPa

Pressure

3050 PSI

Datasheet Content

TS1636




TECHNICAL INFORMATION
Flow (L/min)                        36
Flow (US Gpm)                       9,51
Rotation regime (rpm)               1750
Pressure (MPa)                      16
Pressure (bar)                      160
Pressure (psi)                      2320
Power (hp)                          15
Power (kW)                          11,02
Overall dimensions L x l x h (mm)   327x236x180
Weight (kg)                         15




TS1636                                            3/21/2026   Page 1 - 8
Copyright INTERPUMP GROUP S.P.A
TS1636

     Documents

Male shaft (key)

Male shaft (key) - vers. ATEX




TS1636                            3/21/2026   Page 2 - 8
Copyright INTERPUMP GROUP S.P.A
Illustration Male shaft (key)




TS1636                            3/21/2026   Page 3 - 8
Copyright INTERPUMP GROUP S.P.A
Illustration Male shaft (key)

Pos.     Code           Description                   Qty Notes
KIT6     34000601       KIT 6 PISTON BOLT             1
KIT3     34000301       KIT 3 OIL SEAL D.30X55X7      1
KIT29    34002901       KIT 29 COMPL.SEAL FOR         1
                        PIST.D22
KIT2     34000201       KIT 2 OIL SEAL D. 22X32X5,5   1

KIT169   34016901       KIT 169 INTAKE/DEL.VALVE (66) 1

KIT149   34014901       KIT 149 INT.RING D.22         1
                        W/RESTOP
KIT148   34014801       KIT 148 SEAL D.22X35          1
KIT14    34001401       KIT 14 PACKING RETAINER D.22 1

KIT11    34001101       KIT 11 HEAD RING D. 22        1
54       96738000       WASHER 17,5X23X1,5            1
53       98210000       PLUG G3/8X13                  1
52       96770000       WASHER 26,5X32X1,5            1
51       98226800       PLUG G3/4X16                  1
50       46100051       HEAD RING D. 22               3
49       90272500       PACKING 22x35                 3
48       90273000       RESTOP RING D.22 TYPE 6/1     3


47       47217070       INTERMEDIATE RING             3
                        D.22-RESTOP
46       90272800       PACKING 22X35X9 LP            3
45       47080670       PACKING RETAINER D. 22x35     3


44       90361600       O-RING 34,65X1,78 (2137)      3
43       99364400       SCREW M 10x18-5931            4
42       96710600       WASHER 10,2                   4
41       47200074       PUMP FOOT                     2
40       90164800       OIL SEAL 30x55x7              1
40       97567800       SHIM D.74,5X104X0,1           1
39       97568000       SHIM D.74.5X104X0.3           1
38       47151022       OPEN SIDE COVER (47-66)       1
37       47219566       PISTON SCREW                  3
36       96728000       WASHER 14X18,5X0,5            3
35       90506700       ANTI-EXTRUSION RING           3
34       47040509       PISTON D. 22x50               3
33       96728600       WASHER 14X28X0,5              3
32       47225570       SPACER D.14X20.5X2.5          3
31       90055700       CIRCLIP D.12 UNI 7435         6
30       97738000       CONNECTING-ROD PIN            3
                        D.13X35,5
29       47221301       OIL SIGHT GLASS ASSY G3/4     1




TS1636                                                            3/21/2026   Page 4 - 8
Copyright INTERPUMP GROUP S.P.A
Illustration Male shaft (key)

Pos.   Code             Description                   Qty Notes

28     98204250         PLUG G1/4"x12                 1
27     90358500         O-RING 10,82X1,78 (2043)      4
26     99188400         SCREW M 6x20 UNI 5931         5
25     47160622         CRANKCASE COVER               1
24     99309900         SCREW M 8x35 UNI 5931         6
23     47030001         CONNECTING ROD                3
22     47050466         PISTON GUIDE - S.S.           3
21     91489200         KEY 8(h9)X7X35 UNI 6604/A     1


20     47022335         CRANKSHAFT C. 19              1
19     90392200         O-RING D.133.02X 2,62(3525)   1


18     47010822         CRANKCASE                     1
17     98210600         OIL DIP-STICK G3/8X80         1
16     90912600         BUSHING 22X25X30              3
15     90162500         OIL SEAL 22x32x5              3
14     91837500         TAPER BEARING                 2
13     90391300         O-RING 67,95X2,62 (3268)      2
12     47151122         CLOSED SIDE COVER (47-66)     1


11     99303900         SCREW M 8x16 UNI 5931         8
10     36712701         INTAKE/DEL.VALVE ASSY(66)     6


9      98230000         PLUG M32X1,5X17,5             6
8      90386400         O-RING D.28.25x2.62 90sh(3112) 6


7      36203551         VALVE CAGE                    6
6      94738800         SPRING Dm. 10x18.5            6
5      36203476         SPHERICAL VALVE               6
4      36203366         VALVE SEAT                    6
3      90385700         O-RING 23,81X2,62 (132)       6
2      99322000         SCREW M8X75 UNI5931 12.9      8
1      47123041         PUMP MANIFOLD                 1




TS1636                                                            3/21/2026   Page 5 - 8
Copyright INTERPUMP GROUP S.P.A
Illustration Male shaft (key) - vers. ATEX




TS1636                                       3/21/2026   Page 6 - 8
Copyright INTERPUMP GROUP S.P.A
Illustration Male shaft (key) - vers. ATEX

Pos.     Code           Description                   Qty Notes
KIT6     34000601       KIT 6 PISTON BOLT             1
KIT3     34000301       KIT 3 OIL SEAL D.30X55X7      1
KIT29    34002901       KIT 29 COMPL.SEAL FOR         1
                        PIST.D22
KIT2     34000201       KIT 2 OIL SEAL D. 22X32X5,5   1

KIT169   34016901       KIT 169 INTAKE/DEL.VALVE (66) 1

KIT149   34014901       KIT 149 INT.RING D.22         1
                        W/RESTOP
KIT148   34014801       KIT 148 SEAL D.22X35          1
KIT14    34001401       KIT 14 PACKING RETAINER D.22 1

KIT11    34001101       KIT 11 HEAD RING D. 22        1
60       99180900       SCREW M06X10 5931 A2-70       1
59       96693950       WASHER 6.4x11.0x0.7 D6798A    1
                        INOX
57       90387700       O-RING 39,34X2,62 (3156)      1
56       70211751                                     1
55       90075500       STOP RING J45 UNI7437         1
54       96738000       WASHER 17,5X23X1,5            1
53       98210000       PLUG G3/8X13                  1
52       96770000       WASHER 26,5X32X1,5            1
51       98226800       PLUG G3/4X16                  1
50       46100051       HEAD RING D. 22               3
49       90272500       PACKING 22x35                 3
48       90273000       RESTOP RING D.22 TYPE 6/1     3


47       47217070       INTERMEDIATE RING             3
                        D.22-RESTOP
46       90272800       PACKING 22X35X9 LP            3
45       47080670       PACKING RETAINER D. 22x35     3


44       90361600       O-RING 34,65X1,78 (2137)      3
43       99364400       SCREW M 10x18-5931            4
42       96710600       WASHER 10,2                   4
41       47200074       PUMP FOOT                     2
40       90164800       OIL SEAL 30x55x7              1
40       97567800       SHIM D.74,5X104X0,1           1
39       97568000       SHIM D.74.5X104X0.3           1
38       47151022       OPEN SIDE COVER (47-66)       1
37       47219566       PISTON SCREW                  3
36       96728000       WASHER 14X18,5X0,5            3
35       90506700       ANTI-EXTRUSION RING           3
34       47040509       PISTON D. 22x50               3




TS1636                                                            3/21/2026   Page 7 - 8
Copyright INTERPUMP GROUP S.P.A
Illustration Male shaft (key) - vers. ATEX

Pos.   Code             Description                   Qty Notes

33     96728600         WASHER 14X28X0,5              3
32     47225570         SPACER D.14X20.5X2.5          3
31     90055700         CIRCLIP D.12 UNI 7435         6
30     97738000         CONNECTING-ROD PIN            3
                        D.13X35,5
29     98226600         PLUG G3/4X16 S.S.             1
28     98203600         PLUG G1/4x8 FOR PROBE D.6     1
                        S.S.
27     90358500         O-RING 10,82X1,78 (2043)      4
26     99188400         SCREW M 6x20 UNI 5931         5
25     47160622         CRANKCASE COVER               1
24     99309900         SCREW M 8x35 UNI 5931         6
23     47030001         CONNECTING ROD                3
22     47050466         PISTON GUIDE - S.S.           3
21     91489200         KEY 8(h9)X7X35 UNI 6604/A     1


20     47022335         CRANKSHAFT C. 19              1
19     90392200         O-RING D.133.02X 2,62(3525)   1


18     47010822         CRANKCASE                     1
17     98210700         OIL DIPSTICK G3/8X64          1
                        D4+FILTER ATEX
16     90912600         BUSHING 22X25X30              3
15     90162500         OIL SEAL 22x32x5              3
14     91837500         TAPER BEARING                 2
13     90391300         O-RING 67,95X2,62 (3268)      2
12     47151322         SIDE CRANKCASE COVER (ATEX) 1


11     99303900         SCREW M 8x16 UNI 5931         8
10     36712701         INTAKE/DEL.VALVE ASSY(66)     6


9      98230000         PLUG M32X1,5X17,5             6
8      90386400         O-RING D.28.25x2.62 90sh(3112) 6

7      36203551         VALVE CAGE                    6
6      94738800         SPRING Dm. 10x18.5            6
5      36203476         SPHERICAL VALVE               6
4      36203366         VALVE SEAT                    6
3      90385700         O-RING 23,81X2,62 (132)       6
2      99322000         SCREW M8X75 UNI5931 12.9      8
1      47123041         PUMP MANIFOLD                 1




TS1636                                                            3/21/2026   Page 8 - 8
Copyright INTERPUMP GROUP S.P.A

Technical Documents

(1)

Technical Data Sheet

PDF Document

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

Pratissoli Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

Frequently Asked Questions

What is the Pratissoli PUMP SN7045 R used for?

The Pratissoli PUMP SN7045 R is an industrial positive-displacement pump used for high-pressure hydraulic systems in manufacturing and mobile equipment. It delivers 45 L/min at 210 bar, making it suitable for powering presses, injection moulding machines, and hydraulic power units in industrial applications.

What are the specifications of the Pratissoli PUMP SN7045 R?

The Pratissoli PUMP SN7045 R delivers 45 L/min at 210 bar, with a power rating of 18.4 kW at 1450 rpm. It weighs 43 kg and has overall dimensions of 387 mm (L x l x h). The pump features a male shaft with key and is designed for continuous industrial use.

Where to buy the Pratissoli PUMP SN7045 R in Singapore?

3G Electric supplies the Pratissoli PUMP SN7045 R to customers in Singapore. We handle logistics, customs clearance, and delivery to your facility. Contact our team for a quotation and lead time on this industrial pump.

How to select the correct Pratissoli pump for my system?

To select the correct Pratissoli pump, match the required flow and pressure to the pump's rated output. For the SN7045 R, ensure your system operates within 45 L/min and 210 bar. Verify the shaft type (male keyed) and mounting dimensions. Consult the Interpump Group datasheet for detailed specifications.

Used in

Common applications for Pratissoli

High-pressure industrial cleaning systems — Pratissoli SN7070F and SN71106F pumps (130–200 bar) for sustained pump duty in fixed or mobile wash equipment

Marine and shipboard hydraulic systems — SS7061H and SS71153 pumps rated 150–160 bar for deck machinery and propulsion auxiliaries requiring compact, reliable units

Construction equipment hydraulics — SN7193 and SN71106 models (200–210 bar) for excavator, loader, and crane power-transmission circuits

Industrial press and forming machinery — Pratissoli pump assemblies with ZR1X regulating valves (400 bar) for closed-loop pressure control in metal-working and rubber-molding lines

Mining and aggregates processing — Long-duty SS and SN series pumps (130–160 bar) supplying conveyor drives, screen shakers, and mobile crusher circuits

Oil and gas transfer and metering — Pratissoli regulating-valve models (H168A, R1/200) in skid-mounted pump packages for fluid loading, injection, and line-pressure stabilization

Spare Parts & Repair Kits

Official SN7045 parts list — 83 parts, 41 available in catalog

Official Parts List

SN7045 — Male shaft (key) - GAS exploded diagram

Repair Kits — Order These for Routine Maintenance

KIT2156

KIT 2156*CONROD BUSHING

34215601×1Available

Pratissoli PUMP SN7045 R

Local availability & support — Singapore

Technical Specifications

Datasheet Content

Technical Documents

Need installation or engineering help?

Ask a question

Product Description

Frequently Asked Questions

Used in

Spare Parts & Repair Kits

Recommended Spare Parts

Pratissoli Products

You might also need
